Instruments
29
Low Fuel Warning Light
The low fuel warning light will
illuminate when there is
approximately 1 gallon (4 liters)
of fuel remaining in the tank.
General Warning Symbol
The general warning symbol will
be shown in the information tray
if an ABS or engine management
fault has occurred and the ABS and/or
MIL warning lights are illuminated.
Contact an authorized Triumph dealer
as soon as possible to have the fault
checked and rectified.
Ambient Air Temperature
The ambient air temperature is
displayed as either
o
C or
o
F.
When the motorcycle is stationary
the heat of the engine may affect the
accuracy of the ambient temperature
display.
Once the motorcycle starts moving the
display will return to normal after a
short time.
To change the temperature from °C or
°F, see
page 54.
Speedometer and Odometer
The speedometer indicates the road
speed of the motorcycle.
The odometer shows the total distance
that the motorcycle has traveled.
A
15:53
12.4
°
C
10k
0
0 5 60
7
3443 mi
OR APR 2019
Service In
mi
7
0
N
2
1
1. Speedometer
2. Odometer
This information is available in the
Service tray.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triumph Rocket 3 R and is the answer not in the manual?

Triumph Rocket 3 R Specifications

General IconGeneral
Displacement2458 cc
Bore x Stroke110.2 mm x 85.9 mm
Compression Ratio10.8:1
Max Torque221 Nm @ 4, 000 rpm
Fuel SystemMultipoint sequential electronic fuel injection
Final DriveShaft
Gearbox6-speed
SwingarmSingle-sided, cast aluminium
Front Tyre150/80 R17 V
Rear Tyre240/50 R16 V
Seat Height773 mm
Dry Weight291 kg
Wheelbase1677 mm
Engine TypeLiquid-cooled, DOHC, inline 3-cylinder
Max Power165 hp (123 kW) @ 6000 rpm
ExhaustStainless steel 3 into 1 headers with 3 exit silencer
ClutchHydraulic, torque assist
FrameFull aluminium frame
Front SuspensionShowa 47 mm upside-down
Rear SuspensionShowa monoshock with piggyback reservoir, adjustable
Front BrakesBrembo Stylema® 4-piston radial monobloc calipers
Rear BrakesBrembo 4-piston monobloc caliper
Front Wheel17 x 3.5 in
Rear Wheel16 x 7.5 in
Fuel Tank Capacity18 L
Instrument DisplayTFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
