Triumph Rocket 3 R User Manual

Instruments
54
Display Setup - Units
There are different units of
measurement options that can be
shown in the display screen.
To select the units of measurement
required:
•
From the Display Setup menu, push
the joystick down to select Units
and press the joystick center to
confirm.
•
Push the joystick down/up to
select the required unit; Distance/
Economy, Temperature or Pressure.
•
Push the joystick down/up to select
the required unit of measurement
from the following options:
–
Distance/Economy:
–
Miles and MPG (UK)
– Miles and MPG (US)
– KM and L/100KM
– KM and KM/L
– Temperature:
–
°C
– °F
– Pressure:
–
PSI
– Bar
– KPa
• Press the joystick center to confirm.

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
