Triumph Rocket 3 R User Manual

General Information
93
Both during and after breaking-in has
been completed:
•
Do not overrev the engine when
cold;
•
Do not lug the engine. Always
downshift before the engine begins
to 'struggle';
•
Do not ride with engine speeds
unnecessarily high. Shifting up a
gear helps reduce fuel consumption,
reduces noise and helps to protect
the environment.
Daily Safety Checks
cboc
Warning
Failure to perform these checks
every day before you ride may result
in serious motorcycle damage or an
accident causing serious injury or
death.
Check the following items each day
before you ride. The time required is
minimal, and these checks will help make
sure you have a safe, reliable ride.
If any irregularities are found during
these checks, refer to the Maintenance
and Adjustment section or see your
authorized Triumph dealer for the action
required to return the motorcycle to a
safe operating condition.
Check:
Fuel: Adequate supply in tank, no fuel
leaks (see
page 79).
Engine Oil: Correct level shown on
dipstick. Add correct specification oil as
required. No leaks from the engine or oil
cooler (see
page 123).
Final Drive: No oil leaks (see
page 133).
Tires/Wheels: Correct inflation
pressures (when cold). Tread depth/
wear, tire/wheel damage, punctures etc.
(see
page 144).

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
