The bar end mirrors will be set by your
authorized Triumph dealer and will not
normally require any adjustment. Should
adjustment be necessary, do not rotate
the mirror beyond 75°, measured from
the vertical section of the mirror arm.
1. Mirror arm vertical section
Jacking Points
Warning
This motorcycle is equipped with
jacking points on the engine sump.
Use of the jacking points requires
specialist lifting equipment.
Attempting to lift the motorcycle
without using the jacking points,
or without using the correct lifting
equipment, may result in the
motorcycle falling, causing injury
to the operator or damage to the
motorcycle.
Jacking or lifting of this motorcycle
should only be carried out by an
authorized Triumph dealer, who will
have the correct training and lifting
equipment to safely lift the motorcycle.
The jacking points are located on the
engine sump.
1. Front jacking points
2. Rear jacking points
