General Information
66
RUN Position
The engine start/stop switch must be in
the RUN position for the motorcycle to
operate.
QUICK START Position
The QUICK START position operates the
electric starter allowing for a quicker
ignition start.
From the ignition off, press and hold
the engine start/stop switch in the
QUICKSTART position with all the correct
conditions met, to start the motorcycle.
For more information, see
page 96.
HOME Button
The HOME button is used to access the
main menu on the instrument display.
Press and release the HOME button
to select between the main menu and
instrument display.
Left Handlebar Switches
5
6
1
2
3
7
8
4
1. Cruise control adjust switch
2. Daytime Running Lights (DRL) switch
(if equipped)
3. MODE button
4. Turn signal switch
5. Joystick button
6. Horn button
7. Heated grips switch
8. High beam button
Cruise Control Adjust Button
The cruise control adjust button is a
two way switch with the top marked
RES/+ and the bottom marked SET/-.
For more information on cruise control
operation, see
page 71.
Daytime Running Lights (DRL)
Switch (if equipped)
When the ignition is switched
ON and the daytime running
lights switch is set to DRL
mode, the daytime running
lights warning light will illuminate.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triumph Rocket 3 R and is the answer not in the manual?

Triumph Rocket 3 R Specifications

General IconGeneral
Displacement2458 cc
Bore x Stroke110.2 mm x 85.9 mm
Compression Ratio10.8:1
Max Torque221 Nm @ 4, 000 rpm
Fuel SystemMultipoint sequential electronic fuel injection
Final DriveShaft
Gearbox6-speed
SwingarmSingle-sided, cast aluminium
Front Tyre150/80 R17 V
Rear Tyre240/50 R16 V
Seat Height773 mm
Dry Weight291 kg
Wheelbase1677 mm
Engine TypeLiquid-cooled, DOHC, inline 3-cylinder
Max Power165 hp (123 kW) @ 6000 rpm
ExhaustStainless steel 3 into 1 headers with 3 exit silencer
ClutchHydraulic, torque assist
FrameFull aluminium frame
Front SuspensionShowa 47 mm upside-down
Rear SuspensionShowa monoshock with piggyback reservoir, adjustable
Front BrakesBrembo Stylema® 4-piston radial monobloc calipers
Rear BrakesBrembo 4-piston monobloc caliper
Front Wheel17 x 3.5 in
Rear Wheel16 x 7.5 in
Fuel Tank Capacity18 L
Instrument DisplayTFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
