Triumph Rocket 3 R User Manual

Instruments
31
A low fuel warning message will appear
in the information tray. Press the
joystick center to acknowledge and hide
the low fuel warning.
After refueling, the fuel gage and range
to empty information will be updated
only while riding the motorcycle.
Depending on the riding style, updating
could take up to five minutes.
Gear Position Display
The gear position display indicates
which gear (one to six) has been
engaged. When the transmission is in
neutral (no gear selected), the display
will show N.
A
25:20
hh:mm
02:25
0145
mph
mi
15:53
12.4
°
C
007
4
8
2
Trip 1
mi
0
N
1
1. Gear position display (neutral position
shown)
A
25:20
hh:mm
02:25
0145
mph
mi
15:53
12.4
°
C
0 0 74 82
Trip 1
mi
0
3
1
1. Gear position display (third gear shown)

Triumph Rocket 3 R Specifications

General

Displacement	2458 cc
Bore x Stroke	110.2 mm x 85.9 mm
Compression Ratio	10.8:1
Max Torque	221 Nm @ 4, 000 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Shaft
Gearbox	6-speed
Swingarm	Single-sided, cast aluminium
Front Tyre	150/80 R17 V
Rear Tyre	240/50 R16 V
Seat Height	773 mm
Dry Weight	291 kg
Wheelbase	1677 mm
Engine Type	Liquid-cooled, DOHC, inline 3-cylinder
Max Power	165 hp (123 kW) @ 6000 rpm
Exhaust	Stainless steel 3 into 1 headers with 3 exit silencer
Clutch	Hydraulic, torque assist
Frame	Full aluminium frame
Front Suspension	Showa 47 mm upside-down
Rear Suspension	Showa monoshock with piggyback reservoir, adjustable
Front Brakes	Brembo Stylema® 4-piston radial monobloc calipers
Rear Brakes	Brembo 4-piston monobloc caliper
Front Wheel	17 x 3.5 in
Rear Wheel	16 x 7.5 in
Fuel Tank Capacity	18 L
Instrument Display	TFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
