General Information
83
Seats
Caution
To prevent damage to the seats or
seat covers, care must be taken not to
drop the seats.
Do not lean the seats against the
motorcycle or any surface which may
damage the seats or seat covers.
Instead, place the seats, with the seat
cover facing upwards, on a clean, flat
surface which is covered with a soft
cloth.
Do not place any item on the seats
which may cause damage or staining
to the seat covers.
For seat cleaning information, see
page 168.
Seat Lock
Warning
To prevent detachment of the seat
during riding, after installation always
grasp the seat and pull firmly upwards.
If the seat is not correctly secured in
the lock, it will detach from the lock.
A loose or detached seat may cause
loss of motorcycle control and an
accident.
Caution
The motorcycle must not be ridden
with the key in the seat lock.
Always lock the seat and remove the
key before riding the motorcycle.
The seat lock is located on the left hand
side of the motorcycle, below the seat
and near the oil filler cap.
1
1. Seat lock
The seat can be removed to gain
access to the battery, fuses, storage
compartment and USB socket.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triumph Rocket 3 R and is the answer not in the manual?

Triumph Rocket 3 R Specifications

General IconGeneral
Displacement2458 cc
Bore x Stroke110.2 mm x 85.9 mm
Compression Ratio10.8:1
Max Torque221 Nm @ 4, 000 rpm
Fuel SystemMultipoint sequential electronic fuel injection
Final DriveShaft
Gearbox6-speed
SwingarmSingle-sided, cast aluminium
Front Tyre150/80 R17 V
Rear Tyre240/50 R16 V
Seat Height773 mm
Dry Weight291 kg
Wheelbase1677 mm
Engine TypeLiquid-cooled, DOHC, inline 3-cylinder
Max Power165 hp (123 kW) @ 6000 rpm
ExhaustStainless steel 3 into 1 headers with 3 exit silencer
ClutchHydraulic, torque assist
FrameFull aluminium frame
Front SuspensionShowa 47 mm upside-down
Rear SuspensionShowa monoshock with piggyback reservoir, adjustable
Front BrakesBrembo Stylema® 4-piston radial monobloc calipers
Rear BrakesBrembo 4-piston monobloc caliper
Front Wheel17 x 3.5 in
Rear Wheel16 x 7.5 in
Fuel Tank Capacity18 L
Instrument DisplayTFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
