General Information
72
Activating Cruise Control
The following conditions must be met to
activate cruise control:
The motorcycle must be traveling
at a speed between 30 to 100 mph
(48 to 160 km/h).
The motorcycle must be in third
gear or higher.
mi
30
25:20
hh:mm
02:25
0143
15:53
mph
007 4 82
Trip 1
HOLD TO RESET
4
12.4
°
C
1
2 3
1. Cruise control symbol
2. Cruise control set indicator
3. Cruise control set speed
To activate cruise control:
Press the cruise control button to
turn the cruise control system on.
The cruise control symbol will be
shown in the display screen.
When the required cruising speed
is achieved. press the cruise control
button again to activate the cruise
control.
The word SET will be shown next
to the cruise control symbol. The
cruise control set speed will then be
shown.
The cruise control system will
maintain the set speed until the
cruise control is deactivated as
described on page 72.
Deactivating Cruise Control
The cruise control can be deactivated
by one of the following methods:
Roll the throttle twist grip fully
forward.
Pull the clutch lever.
Operate the front or rear brake.
Increase speed by using the throttle
for more than 60 seconds.
Upon deactivation, the cruise control
symbol will disappear but the SET
indicator and set speed will still be
shown in the display screen, indicating
that the cruise control set speed has
been stored.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triumph Rocket 3 R and is the answer not in the manual?

Triumph Rocket 3 R Specifications

General IconGeneral
Displacement2458 cc
Bore x Stroke110.2 mm x 85.9 mm
Compression Ratio10.8:1
Max Torque221 Nm @ 4, 000 rpm
Fuel SystemMultipoint sequential electronic fuel injection
Final DriveShaft
Gearbox6-speed
SwingarmSingle-sided, cast aluminium
Front Tyre150/80 R17 V
Rear Tyre240/50 R16 V
Seat Height773 mm
Dry Weight291 kg
Wheelbase1677 mm
Engine TypeLiquid-cooled, DOHC, inline 3-cylinder
Max Power165 hp (123 kW) @ 6000 rpm
ExhaustStainless steel 3 into 1 headers with 3 exit silencer
ClutchHydraulic, torque assist
FrameFull aluminium frame
Front SuspensionShowa 47 mm upside-down
Rear SuspensionShowa monoshock with piggyback reservoir, adjustable
Front BrakesBrembo Stylema® 4-piston radial monobloc calipers
Rear BrakesBrembo 4-piston monobloc caliper
Front Wheel17 x 3.5 in
Rear Wheel16 x 7.5 in
Fuel Tank Capacity18 L
Instrument DisplayTFT multi-functional instrument pack with digital speedometer, trip computer, digital tachometer, gear position indicator, fuel gauge, service indicator, ambient temperature, clock and rider modes
