MODEL 3587 - 38 -
6.1.3 Operation
Ta Command Response time ：MAX Approximately 5 ms
Tb After response, command prohibition time ：RS-232C MAX 5 ms
Note: When data communication is undertaken, set ONLINE of GENERAL setting
to ON. (Section 3.8.7) If the communication is undertaken at OFF condition
of ONLINE, an error message is obtained except in read command.
Ta Tb
3587
Higher level
(Computer)
Command frame Command frame
Response frameResponse frame
To Next Page
