MODEL 3587 - 52 -
◆ System setting
Item Setting range Contents Initial setting User setting
DISCHARGE ENABLE Automatic discharge enabled, after measurement.
ENABLE
DISABLE Automatic discharge disabled, after measurement.
CONTRAST 1 to 5 Brightness of front-panel 3
◆ Other setting
Item Setting range Contents Initial setting User setting
LOCK ON, OFF Key locking, Enable/Disable of operating by keys OFF
11.6 External dimensions
Unit: mm
11.7 Option
Panel-mount bracket : Model 5811-31
LOW probe : Model 5813-21
HIGH probe : Model 5813-22
Probe with switch : Model 5813-23
Power supply cord for AC 200V : Model 5880-23-030
64
205 169
11.5
51
HIGH
GOOD
LOW
START STOP
３５８７ＭＯＤＥＬ
ＬＯＷ
ＲＥＭＯＴＥ
ＧＵＡＲＤ
ＨＩＧＨ
100- 240V 50-60Hz
AC LINE 28V A MAX
O-COM GO LO HI CHG C-ERR TEST I-COM MEM1 MEM2 MEM4 MEM8 START RESET
CONTROL
PN
RS-232C
LOW
HIGH
L CONTACT
H CONTACT
100-24 0V 50-60Hz
AC LINE 28VA MAX
O-COM GO LO HI CHG C-ERR TEST I-COM MEM1 MEM2 MEM4 MEM8 START RESET
CONTROL
PN
RS-232C
LOW
HIGH
L CONTACT
H CONTACT
BCD OC OUT
[ SET ] [ ] [ LOCK ]
MΩ
１２．３４
99.9 s 9 9.9 s
TIMER MASK
999.9
000.0
MΩ
No.1 0 1000V 2000 MΩ M
F3F2F1
HI SET
LO SET
MΩ
TEST
[RCL]
F4
With BCD output
