- 51 - MODEL 3587
11.5 Table of factory setting
◆ Memory setting
Item Setting range Contents Initial setting User setting
Memory No. 01 to 10 Memory number 1
TEST MODE AUTO Automatic measurement
AUTO
CONTINUE Continuous measurement
VOLTAGE 25 to 1050v Measuring voltage 25V
RANGE 2MΩ Resistance range
200MΩ
20MΩ
200MΩ
2000MΩ
AUTO Auto
HIGH SET 0-9999, OFF Comparator, Upper-limit 9000
LOW SET 0-9999, OFF Comparator, Lower-limit 1000
COMP RAG 2MΩ Comparator range
200MΩ
20MΩ
200MΩ
2000MΩ
TIMER 0.2 to 99.9 Timer 1.0
MASKTIMER 0.1 to 99.9, OFF Mask timer 0.2
◆ Tester setting
Item Setting range Contents Initial setting User setting
REMOTE MANUAL Manual mode
Manual
REMOTE1 Remote1(Terminal on rear-panel)
REMOTE2 Remote2(Remote-Connector)
EXT.CTRL OFF Select memory on Front-panel key
OFF
ON Select memory by terminal on rear-panel
SAMPLING FAST 50 times/s. or 60 times/s.
FAST
SLOW 10 times/s.
POWER FRQ 50Hz Fixed at 50Hz
50 Hz
60Hz Fixed at 60Hz
CNTCT CHK OFF No contact check
OFF
ON Do contact check
BUZZ MODE OFF Buzzer off
OFF
GOOD With buzzer by GOOD judgement
NG With buzzer by NG judgement
BUZZ VOL 1 to 9 Volume of buzzer 5
ONLINE OFF Communication control disabled (Readout enabled)
OFF
ON Communication control enabled
RS BPS 9600bps Baud rate setting of RS-232C
9600bps
19200bps
38400bps
RS PARITY NONE OFF: RS-232C parity
NONE
EVEN Even: RS-232C parity
ODD Odd: RS-232C parity
