MODEL 3587 - 2 -
1.1 Preparations prior to use
●Unpacking
When the tester is delivered, please check whether it conforms to the required specifications
and has not been damaged in transit. If there is any damage on the tester or it does no work in
conformity with the specifications, please inform us of the model and product name.
●Storage
In case of storing the tester for a long time, store it at the place of low humidity and where it is
not exposed to the direct sunlight.
1.2 Confirmation prior to use
● Power supply
Use the tester with the power source voltage within 90 to 250VAC and the frequency 50/60Hz.
When connecting the power supply cable, confirm that the power supply switch is turned OFF.
! Warning
●Set the power switch for the instrument where it can be used very easily.
●Power supply cable
The plug of power supply cable connected to the tester is for 100VAC use. When the tester is
used with 200VAC, replace the plug with appropriate one for 200VAC use. Please connect the
power supply cable to the power supply connector on the rear panel of the tester. The plug of
power supply cable has 3 pins and the round shape pin in the center is for grounding.
