33
electrical interface specifications and functions are the same as the AC Control Box.
2.2.2. Definition of Industrial Connector
4-Pin Industrial Connector (External 24V Power )
Industrial connector wire sequence
Functional definition
1
24V
2
GND
3
Null
4
Null
