UFactory xArm 5 User Manual

35
1. Interfering signals above the level specified in the IEC
standard will cause abnormal behaviour of the robotic arm.
Extremely high signal levels or excessive exposure can
cause permanent damage to the robotic arm. UFACTORY
(Shenzhen) Technology Co., Ltd. is not responsible for any
loss caused by EMC problems.
2. The length of the I/O cable that used to connect the Control
Box with other mechanical and plant equipment must not
exceed 30 meters unless it is feasible after the extension
testing.
When wiring the electrical interface of the Control Box,
the Control Box must be powered off.
2.3. End-Effector I/O
At the tool side of the robotic arm, there is an avionic socket 12-pin female industrial
connector. This connector provides power and control signals for the grippers and
sensors used on a particular robotic arm tool. Please refer to the figure below:
