Compressor Unit Instruction Manual
Do not place objects or equipments on top of a compressor. It prevents heat release from the
compressor as well as applying unnecessary heat to the equipments placed on it.
CAUTION
1.5.2 Dimensions
Figure 1-2 shows the dimensions.
(Front) (Side)
Figure 1-2 C30HVRT Compressor dimensions
1.5.3 Weight
Table 1-1 shows weights of different types of compressor.
Table 1-1 Compressor weight
Model Weight [kg]
C30HVRT 121
*The weights in this table are of standard compressors. The weight depends on the
specifications of the customer’s order.
