Ulvac C30HVRT - Carton Contents; Figure 3 2 Remove Cardboard and Insert Forks Underneath the Compressor; Table 3-1 Carton Contents

Compressor Unit Instruction Manual
ULVAC CRYOGENICS INCORPORATED
3-3
It is highly recommended to keep the package cardboard box, wooden bottom plate, and
other packaging materials. The packages can be used for storage and transport of the
compressor or for returning it to us for servicing.
Figure 3-2 Remove Cardboard and Insert Forks underneath the Compressor
3.4 Carton Contents
When a product(s) delivered, make sure that there is no damage or shortage of delivered
items by checking the external view of the package and the shipping list attached.
Please read the enclosed cover letter for the details. Depending on your specification, the
option part(s) in Table 3-2 is attached.
Table 3-1 Carton Contents
Item Quantity
Compressor 1
Manual 1
Connector for remote operation 1
Table 3-2 Optional parts
Item Quantity
Input power cable ( 3m or customized length) 1
Refrigerator cable( 3m or customized length) 1
Flexible hose ( 3m or customized length) 2
Lipped bowl spanner (flexible hoses installing tool) 2
Gasket for helium coupling (spare) 4
Direction of inserting forks
of the forklift
Remove the cardboard
Compressor
Side
Bottom frame
Compressor
Front
