Section 1 C30HVRT Compressor Description
1.5.4 General specifications
The tables below show power supply rating, cooling water requirements, installation
environment, operation requirements and electromagnetic environment resistance
characteristics. (Tables 1-2～1-5)
Table 1-2 Power supply rating
Item
C30HVRT
Rated working voltage 50Hz 190 – 220 VAC
60Hz 200 – 230 VAC
Power phase 3
Stationary power
consumption
(*3)
50Hz
5.8kW
60Hz 7.2kW
Power factor 0.85
Stationary electric current
consumption
(*
１
)(*3)
50Hz
20A
60Hz 23A
Locked rotor electric current 151A
Customer-supplied rated electric
current (minimum)
(*2)
40A/ 5kA
Grounding D class grounding
(with the ground resistance of 100Ωor less)
(*
１
)
During cooling down of the cryocooler, until it stabilizes at a low temperature, the electric current value is
about 10% larger than the stationary electric current.
Longer flexile hoses also increase the electric current. (A set of 20m flexible hose will increase the electric
current by 5% compared to the nominal value.
(*2)
Circuit Breaker Current Rating / Interrupt Rating
(*3)
Cryocooler opration at 20K
Table 1-3 Cooling water requirements
Item Requirements
Water temperature (Cooling water inlet)
5 – 32 ℃
Flow rate 5 - 15 L/min
Cooling water supply pressure Max. 0.7MPaG
Pressure drop (water inlet to water outlet) 0.02 – 0.17MPa (See Fig. 2-3)
Alkalinity (pH) 6.5 – 8.0 pH
Calcium Carbonate < 75ppm
Refer to “Section 2.4 Cooling water requirements” for more details.
Table 1-4 Installation environment and operation requirements
Item
Requirements
C30HVRT,
Ambient operating temperature
10 – 35 ℃
Ambient storage temperature
-10 – 55 ℃
Humidity 5 - 90% (non-condensing)
Altitude < 1000m
Vibration < 0.6G, 10 – 55 Hz
Atmosphere Free from metal powder, dust,
flammable and corrosive gas
Static helium pressure
at 20 ℃
(*1)
1.5±0.04MPaG
Sound pressure level
during operation
< 70 dBA
Refer to “Section5.1 Verification of helium static pressure” for details.
