Section 1 C30HVRT Compressor Description

This helium line is a closed circuit and helium gas is cycled to use. Therefore refilling

helium gas is not necessary for long time.

Helium gas is compressed in a highly-reliable oil injection type helium compressor.

Helium gas recovers its purity as it flows through an oil separator and an adsorber, where

contaminants are removed.

It is necessary to check the elapsed time of operation and replace adsorber regularly to

maintain cryocooling capacity as well as prevent breakdown of the cryocooler.

Refer to “Section 7.2 Replacement of adsorber”.

The Compressor requires maintenance. Read “Section 7 Maintenance” thoroughly and

conduct regular maintenance.

1.5 Compressor specifications

1.5.1 External view

Figure 1-1 shows external view of C30HVRT.

(Front) (Rear)

Figure 1-1 C30HVRT External view

1-2

ULVAC CRYOGENICS INCORPORATED
