Upright LX31 Service & Parts Manual

Introduction & Specifications
1-2
Section
LX 31/41 Work Platform
1.2
1.2 Specifications
Table 1-1: Specifications
ITEM
Platform Size
(Inside Toeboards)
Standard
w/ Extension
Max. Platform Capacity
Standard
w/ Extension
on Extension
Max. No. of occupants
Standard
on Extension
Height
Working Height
Max. Platform Height
Min. Platform Height
Dimensions
Weight, Standard
w/ Extension
Overall Width
Overall Height
Overall Length, Standard
Driveable Height
Surface Speed
Platform Lowered
Platform Raised
System Voltage
Hydraulic Tank Capacity
Maximum Hydraulic System
Pressure
Hydraulic Fluid
Normal Use (>32 °F [0 °C])
Low Temp. Use
(-10 to 32 °F [-23 to 0 °C])
Lift System
Lift Speed
Platform Leveling
Power Source
Drive Control
Control System
Horizontal Drive
Tires
Parking Brakes
Turning Radius (inside)
Maximum Gradeability
Wheel Base
Guardrails
Toeboard
LX41
143.38 in. x 70 in. [3.64 m x 1.78 m]
179.38 in. x 68 in. [4.56 m x 1.73 m]
1,500 lbs. [680 kg]
1,500 lbs. [680 kg]
500 lbs. [227 kg]
6 people
2 people
47 ft. [14.33 m]
40 ft. 6 in. [12.34 m]
65.25 in. [1.66 m]
2 WD : 10,560 lbs. [4,790 kg] 4 WD : 10,920 lbs. [4,953 kg]
2 WD : 10,990 lbs. [4,985 kg] 4 WD : 11,350 lbs. [5,148 kg]
90 in. [2.29 m]
108.75 in. [2.76 m]
160.5 in. [4.08 m]
40 ft. 6 in. [12.34 m]
0 to 3.1 mph [0 to 5.0 km/h]
0 to 0.3 mph [0 to .48 km/h]
12 Volt DC
28.3 Gallons [107.13 l]
3000 psi [206.8 bar]
ISO #46
5W-20 Motor Oil
One Single Stage Lift Cylinder
Raise, 45 sec./Lower, 65 sec.
8.5
o
(12in. [.3m]) Side/Side, 6
o
(12in. [.3m]) Fore/Aft
Diesel or Gasoline 20 HP Kubota, 3 Cylinder, Water
Cooled Engine
Proportional
Joystick Controller with Interlock Lever and Thumb Rocker
Steering; Speed & Function Selector Switches and
Emergency Stop Button
2 WD : 2 Wheel, Hyd. Motors 4 WD : 4 Wheel, Hyd. Motors
10-16.5 NHS 8 Ply, 50psi [3.4 bar]
Two, Spring Applied, Hydraulic Release, Multiple Disc
48 in. [1.22 m]
2WD: 30% [16.7º] 4WD: 35% [19.3º]
115.75 in. [2.94 m]
43.5 in. [1.1 m] high, Fold Down with Gate
6 in. [152 mm] High
LX31
143.38 in. x 70 in. [3.64 m x 1.78 m]
179.38 in. x 68 in. [4.56 m x 1.73 m]
2000 lbs. [907 kg]
2000 lbs. [907 kg]
500 lbs. [227 kg]
8 people
2 people
37 ft. [11.28 m]
31 ft. [9.45 m]
56.25 in. [1.43 m]
2 WD : 9,220 lbs. [4,182 kg] 4 WD : 9,580 lbs. [4,345 kg]
2 WD : 9,650 lbs. [4,377 kg] 4 WD : 10,010 lbs. [4,540 kg]
90 in. [2.29 m]
99.75 in. [2.53 m]
160.5 in. [4.08 m]
31 ft. [9.45 m]
0 to 3.1 mph [0 to 5.0 km/h]
0 to 0.3 mph [0 to .48 km/h]
12 Volt DC
28.3 Gallons [107.13 l]
3000 psi [206.8 bar]
ISO #46
5W-20 Motor Oil
One Single Stage Lift Cylinder
Raise, 40 sec./Lower, 60 sec.
8.5
o
(12in. [.3m]) Side/Side, 6
o
(12in. [.3m]) Fore/Aft
Diesel or Gasoline 20 HP Kubota, 3 Cylinder, Water
Cooled Engine
Proportional
Joystick Controller with Interlock Lever and Thumb Rocker
Steering; Speed & Function Selector Switches and
Emergency Stop Button
2 WD : 2 Wheel, Hyd. Motors 4 WD : 4 Wheel, Hyd. Motors
10-16.5 NHS 8 Ply, 50psi [3.4 bar]
Two, Spring Applied, Hydraulic Release, Multiple Disc
48 in. [1.22 m]
2WD: 30% [16.7º] 4WD: 35% [19.3º]
115.75 in. [2.94 m]
43.5 in. [1.1 m] high, Fold Down with Gate
6 in. [152 mm] High
NOTE: Specifications subject to change without notice.
