Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-46
ENGINE ASSEMBLY, LX31/41
K
UBOTA DIESEL
67523-002
ITEM PART DESCRIPTION QTY.
1 67614-000 ENGINE, KUBOTA DIESEL 1
* 67614-004 OIL FILTER ELEMENT 1
* 67614-026 FUEL PUMP, LIFT 1
* 67614-009 INJECTION PUMP 1
* 67614-010 INJECTOR NOZZLE 3
* 67614-011 GLOW PLUG 3
* 67614-012 RADIATOR 1
* 67614-013 RADIATOR CAP 1
* 67614-014 THERMOSTAT 1
* 67614-015 WATER PUMP 1
* 67614-018 FAN BELT 1
* 67614-019 ALTERNATOR 1
* 67614-020 VOLTAGE REGULATOR 1
* 67614-022 STARTER 1
* 67614-023 OIL PRESSURE SWITCH 1
* 67614-024 KUBOTA D905 ENGINE PARTS MANUAL 1
* 67614-025 KUBOTA D905 ENGINE SERVICE MANUAL 1
2 67608-000 PUMP, VARIABLE DISPLACEMENT 1
3 67668-001 SOLENOID, THROTTLE 1
* 67668-002 THROTTLE RELAY 1
4 12733-099 HOSE, FUEL LINE 9'
5 20541-001 HOSE CLAMP 6
6 67614-007 FUEL FILTER, INLINE 1
7 27972-000 SOLENOID, STARTER RELAY 1
8 11240-007 WASHER FLAT STD 7/16 12
9 64180-001 ENGINE MOUNT BRACKET 2
10 67614-005 AIR FILTER ELEMENT 1
11 67859-000 BRACKET, AIR CLEANER 1
12 67614-006 FUEL FILTER - SPIN ON CARTRIDGE 1
13 64177-004 WELDMENT, MUFFLER SPACER 1
14 67850-000 BRACKET, SOLENOID/GLOW 1
ITEM PART DESCRIPTION QTY.
15 67870-000 BRACKET, DIESEL FUEL FILTER 1
16 64423-000 INLINE SWIVEL - 1/4 1
17 11760-004 ROD END BEARING - 1/4-28 1
18 11934-008 FITTING 8MB-8MJ 90° 1
19 14338-002 FITTING SPLIT FLANGE - 12MJ 90° 1
20 11254-010 SCREW HHC 3/8-16UNC X 1-1/4 4
21 11238-006 LOCKWASHER, SPLIT 3/8 6
22 67670-012 SPLIT FLANGE - HALF 3/4 2
23 67671-012 O-RING 1
24 67671-020 O-RING 1
25 14338-008 FITTING SPLIT FLANGE - 20MJ 90° 1
26 67670-020 SPLIT FLANGE - 1-1/4 2
27 11255-010 SCREW HHC 7/16-14UNC X 1-1/4 4
28 11238-007 LOCK WASHER SPLIT 7/16 4
29 11252-004 SCREW HHC 1/4-20UNC X 1/2 2
30 11252-008 SCREW HHC 1/4-20UNC X 1 3
31 11240-004 WASHER FLAT STD 1/4 2
32 11238-004 WASHER SPLIT LOCK 1/2 2
33 11248-004 NUT HEX 1/4 ESNA 7
34 67617-000 KTR BELL HOUSING KIT 1
35 11256-010 SCREW HHC 1/2-13UNC X 1-1/4 2
36 11941-001 FITTING STR 4MB-4MJ 1
37 64183-000 SPACER, ENGINE 2
38 11937-001 FITTING 90° 4FJ-4MJ 1
39 11240-006 WASHER FLAT STD 3/8 2
40 63946-030 SCREW HHC M10 X 1.25 GR5 X 30MM 12
41 REF SCREW (SUPPLIED W/ AIR CLEANER) 2
42 REF SCREW MANIFOLD (SUPPLIED W/ ENGINE) 4
43 67672-010 SCREW HHC M8 X 1.25 X 10MM 2
44 11248-003 NUT HEX ESNA 10-24UNC 2
