Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-24
CHASSIS ASSEMBLY, LX31/41
F
OUR WHEEL DRIVE
67519-000
ITEM PART DESCRIPTION QTY.
1 67729-000 CHASSIS WELDMENT 1
2 67700-000 AXLE WELDMENT 1
3 67743-000 TRUNNION (L.H.) 1
4 67742-000 TRUNNION (R.H.) 1
5 67739-000 STEERING LINK 1
6 67812-000 BUSHING 2
7 67813-000 CONNECTING LINK 2
8 67746-000 TRUNNION PIN, LOWER 2
9 67814-000 PIVOT SHAFT, FRONT AXLE 1
10 67748-000 STEERING CLAMP 1
11 11238-012 LOCKWASHER SPLIT 3/4 4
12 67816-000 REAR PLATE WELDMENT 1
13 67607-001 HYDRAULIC MOTOR (FRONT) 2
* 67607-010 HYD. MOT. SEAL KIT 1
14 67600-000 TORQUE HUB 2
* 67600-010 BEARING 2
* 67600-011 SHAFT SEAL 2
* 67600-012 STUD 10
* 67600-013 O-RING 2
15 67603-000 BRAKE 2
* 67603-010 BRAKE SEAL KIT 1
16 67601-001 HYDRAULIC MOTOR 2
* 67601-010 HYD. MOT. SEAL KIT 1
17 67633-000 STEERING CYLINDER 1
* 67633-010 STEER CYL. SEAL KIT 1
18 67634-000 AXLE PIVOT CYLINDER 1
* 67634-010 AXLE PIVOT CYL. SEAL KIT 1
19 67637-000 PIVOT BUSHING 2
20 27931-057 BEARING, PIVOT CYL. 2
21 67606-020 BEARING, SCISSOR PIVOT 2
22 64298-004 BEARING, AXLE PIVOT 2
23 62649-020 BEARING, STEERING ROD 2
24 67606-010 BEARING 6
51 67666-000 TIRE/WHEEL ASSY REAR RHD 1
* 67666-002 TIRE / WHEEL OPTIONAL POLY FILL -
* 67605-000 WHEEL, 16.5 x 8.25, 8 BOLT 1
* 67610-000 TIRE 10-16.5 NHS 8 PLY 1
* 12282-001 VALVE STEM 1
52 67666-001 TIRE/WHEEL ASSY REAR LHD 1
* 67666-003 TIRE / WHEEL OPTIONAL POLY FILL -
* 67605-000 WHEEL, 16.5 x 8.25, 8 BOLT 1
* 67610-000 TIRE 10-16.5 NHS 8 PLY 1
* 12282-001 VALVE STEM 1
27 67664-000 TIRE & WHEEL - RH 4WD FRONT 1
* 67664-002 TIRE / WHEEL OPTIONAL POLLY FILL -
* 67609-000 WHEEL, 16.5 x 8.25, 6 BOLT 1
* 67610-000 TIRE 10-16.5 NHS 8 PLY 1
* 12282-001 VALVE STEM 1
28 67664-001 TIRE & WHEEL - LH 4WD FRONT 1
* 67664-003 TIRE / WHEEL OPTIONAL POLLY FILL -
* 67609-000 WHEEL, 16.5 x 8.25, 6 BOLT 1
* 67610-000 TIRE 10-16.5 NHS 8 PLY 1
* 12282-001 VALVE STEM 1
ITEM PART DESCRIPTION QTY.
29 11252-020 SCREW, HHC 1/4-20UNC X 2-1/2 6
30 11248-004 NUT, HEX 1/4-20 ESNA 6
31 62642-020 BEARING 4
32 67746-001 STEERING LINK PIN 2
33 11254-020 SCREW, HHC 3/8-16UNC X 2-1/2 6
34 11248-006 NUT, HEX 3/8-16UNC ESNA 6
35 11755-012 PIN, COTTER 3/16D X 1-1/2 2
36 11848-050 PIN, CLEVIS 1 X 2-3/4 1
37 13315-011 RETAINING E RING 2
38 11256-020 SCREW, HHC 1/2-13UNC X 2-1/2 2
39 11248-008 NUT, HEX 1/2-13UNC ESNA 11
40 11256-028 SCREW, HHC 1/2-13UNC X 3-1/2 2
41 11256-012 SCREW, HHC 1/2-13UNC X 1-1/2 17
42 11238-008 LOCKWASHER, SPLIT 1/2 37
43 11249-016 LOCKNUT, HEX 1-14UNF ESNA 4
44 11297-016 WASHER, BELL 1" 4
45 64370-001 CYLINDER PIN 1 X 5-1/4 2
46 11258-012 SCREW, HHC 3/4-10UNC X 1-1/2 4
47 12030-032 SCREW, SOC HD 1/2-13UNC X 4 8
48 11469-005 LUG NUT, 9/16-18 90° 10
49 12004-004 FITTING, PLUG SAE#4 4
50 15961-004 FITTING, TEE 4MB - 4MJ - 4MJ 2
51 11934-001 FITTING, 90° 4MB - 4MJ 7
52 11937-001 FITTING, 90° 4FJX - 4MJ 2
53 15961-010 FITTING, TEE 10MB - 10MJ-10MJ 1
54 10150-005 FITTING, BULKHD. 8MJ - 8MJ 4
55 11941-014 FITTING, 12MB - 8MJ 2
56 11935-006 FITTING, 45° 10MB - 10MJ 2
57 11934-011 FITTING, 90° 10MB - 10MJ 1
58 11934-003 FITTING, 90° 6MB - 4MJ 2
59 12030-010 SCREW SOC HD 1/2-13 X 1-1/4 8
60 67878-000 AXLE COVER 4WD 1
61 67674-008 FITTING 45° 12MB - 8MJ 4
62 64296-003 LIMIT SWITCH 1
63 64294-004 CLAMP LEVER 1
64 12002-010 FITTING 10MJ - 10MJ 90° 4
65 64297-001 CHECK VALVE 2
66 11848-051 CLEVIS PIN 1" DIA. X 2" 1
67 63978-000 HAND PUMP (BRAKE) 1
68 11240-006 WASHER 3/8 STD 2
69 12877-008 VALVE BIDIRECTIONAL RELIEF 2
70 67673-001 FITTING 4MJ-4MJ CROSS 1
71 11709-018 SCREW MACH RD HD 10-24 X 2-1/4 4
72 11248-003 NUT HEX ESNA 10-24 4
73 67746-002 TRUNNION PIN UPPER 2
74 11935-003 FITTING 6MB - 6MJ 45° 1
75 11941-005 FITTING 6MB - 6MJ STR 1
76 11252-004 SCREW HHC 1/4-20 X 1/2 2
77 11240-004 WASHER 1/4 FLAT STD 2
78 64279-000 THRUST BEARING 2
80 11469-003 WHEEL NUT, FRONT 12
81 11941-001 FITTING 4MB-4MJ STR 1
82 67805-009 GROMMET MATERIAL 7'
*Not Shown
