Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-70
SLIDEOUT DECK ASSEMBLY, LX31/41
67866-000
ITEM PART DESCRIPTION QTY.
1 67744-000 GUIDE RAIL WELDMENT 2
2 67787-000 SLIDEOUT DECK WELDMENT 1
3 67760-001 WHEEL, SLIDEOUT DECK 2
4 67719-000 ROLLER 2
5 67720-000 ROLLER 2
6 67818-001 ARM, CABLE GUIDE 2
7 67786-001 BRACKET, CABLE GUIDE 1
8 67761-000 PIVOT, PUSH BAR 2
9 67862-001 HANDLE WELDMENT (L.H.) 1
10 67862-002 HANDLE WELDMENT (R.H.) 1
11 67776-001 GUARDRAIL WELDMENT 2
12 67778-000 GUARDRAIL WELDMENT 1
13 67755-001 SWING TUBE 2
14 11848-038 CLEVIS PIN, 1/2" DIA. X 2-1/2 4
15 11239-008 WASHER, FLAT 1/2" DIA. ASTM 4
16 11757-005 RUE RING 4
17 14996-006 WASHER, FLAT 3/8" DIA 11
18 67695-000 SPACER 4
19 11248-006 LOCKNUT, 3/8-16 UNC ESNA 23
20 66556-000 LABEL, WARNING DESCEND PLTFM 2
21 11254-008 SCR. HHC 3/8-16 UNC X 1 6
22 11254-014 SCR. HHC 3/8-16 UNC X 1 3/4 4
23 10414-000 LOCKING PIN ASSY 5/16" DIA. 2
24 11254-020 SCR. HHC 3/8-16 UNC X 2 1/2 13
25 11254-032 SCR. HHC 3/8-16 UNC X 4 4
26 11240-005 WASHER 5/16 FLAT STD 4
27 60086-000 SAFETY WALK (20 X 32) 4
28 66557-001 LABEL PLATFORM CAPCITY 1
29 63728-001 SLIDE BLOCK 1
30 26553-004 POP RIVET 3/16 DIA.(.250-.375) 2
31 63666-004 WIRE CHANNEL 1
32 11253-012 SCR. HHC 5/16-18 X 1-1/2 2
33 11248-005 NUT HEX 5/16-18 ESNA 2
