Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-40
POWER MODULE ASSEMBLY, LX31/41
D
IESEL
67522-002
ITEM PART DESCRIPTION QTY.
1 67809-000 HINGE, 2 X 65 1
2 67811-000 POWER MODULE WELDMENT 1
3 67800-001 MODULE DOOR, R.H. 1
4 67801-001 MODULE DOOR, L.H. 1
5 67799-001 MODULE COVER (DIESEL) 1
6 67808-000 HINGE, 2 X 22 2
7 26554-002 POP RIVET, 1/4 DIA. (.251 - .375 GRIP) 42
8 05299-000 LATCH, TOGGLE 2
9 67629-000 LATCH, FLUSH LIFT & TURN 2
10 67523-002 ENGINE ASSY, DIESEL KUBOTA 1
11 11939-021 FITTING 12MP-12MJ 1
12 11923-012 FITTING 16MP-12FP 1
13 63935-000 SUCTION SCREEN 1
14 67841-000 TANK, HYDRAULIC 1
15 67614-017 MUFFLER ASSY 1
16 25427-002 HANDLE 1
17 26533-002 RIVET POP, 3/16D .126 -.250 GRIP 4
18 67856-000 STIFFENER BAR 1
19 11708-004 SCREW RD HD 8-32 X 1/2 4
20 11248-002 NUT HEX 8-32 ESNA 4
21 11254-006 SCREW HHC 3/8-16 X 3/4 2
22 64039-000 TANK MOUNTING TAB 2
23 67624-000 HYDRAULIC FILTER 1
* 67624-010 ELEMENT, FILTER 1
24 11916-011 ELBOW 90° 20FP-20FP (1-1/4 NPT) 1
25 67614-016 OVERFLOW KIT 1
26 11240-006 WASHER 3/8 FLAT STD 22
27 11254-008 SCREW HHC 3/8-16 X 1 10
28 11248-006 NUT HEX 3/8-16 ESNA 12
ITEM PART DESCRIPTION QTY.
29 63650-012 SPRING, PRESSURIZED GAS 1
30 67648-008 END FITTING, GAS SPRING 2
31 15936-004 SCREW SHOULDER 3/8«» X 1/2 2
32 14902-005 FITTING TEE 12MP-12FP 1
33 11939-030 FITTING 20MP-20MJ 1
34 11939-013 FITTING 8MP-4MJ 1
35 11939-015 FITTING 8MP-8MJ 1
36 67898-000 RADIATOR COVER 1
37 63930-001 BREATHER/FILLER CAP 1
38 21305-007 PLUG, MAGNETIC 1
39 67696-001 EXHAUST TUBE, DIESEL 1
40 67902-000 BRACKET, GAS SPRING 1
41 10070-099 SEAL STRIP GASKET 1.77'
42 67691-000 SNORKEL WELDMENT, DIESEL 1
43 20541-013 HOSE CLAMP 1
44 67697-001 BREATHER SPACER 1
45 11252-008 SCREW HHC 1/4-20 X 1 12
46 11240-004 WASHER FLAT STD 1/4 12
47 11940-014 FITTING 90° 4MP-4MJ 1
48 13259-006 CLAMP, MUFFLER 1-1/2" 2
49 63979-006 GAGE, LUBE SIGHT 1
50 11248-004 NUT HEX ESNA 1/4-20 8
51 66697-099 PIPE INSULATION 1-3/8 DIA. 1
52 11248-005 NUT HEX 5/16-18 ESNA 2
53 11253-007 SCREW HHC 5/16-18 X 7/8 4
54 11240-005 WASHER 5/16 FLAT STD 4
55 11238-005 WASHER LOCK 5/16 4
56 11250-005 NUT HEX 5/16-18 4
57 11923-007 FITTING 12MP-4FP 1
*Not Shown
