Illustrated Parts Breakdown

7.2

SectionSection

Section

LX31/41 Work Platform7-26

SCISSOR LINKAGE ASSEMBLY

LX31

67515-000

ITEM PART DESCRIPTION QTY.

1 67550-000 ARM WELDMENT 1

2 67551-000 ARM WELDMENT 1

3 67552-000 ARM WELDMENT 1

4 67593-000 ARM WELDMENT 2

5 67828-000 ARM WELDMENT 1

6 67830-000 ARM WELDMENT 1

7 67832-000 ARM WELDMENT 1

8 11786-017 MACHINERY BUSHING, 2" ID X 14 GA. 1

9 11734-024 ROLL PIN, 3/8 DIA. X 3" LG. 1

10 67606-020 BEARING, 2" I.D. X 1 1/2" LG. 12

11 67606-030 BEARING, 3" I.D. X 1 1/2" LG. 16

12 67583-000 PIN WELDMENT 4

13 67580-000 PIN WELDMENT 8

14 67585-000 PIN WELDMENT 2

15 67586-000 PIN, CYLINDER 2

16 67635-000 LIFT CYLINDER 1

* 67635-010 SEAL KIT 1

17 14033-048 H.H.C.S. 1/2-13 UNC X 6 GR. 8 8

18 14033-032 H.H.C.S. 1/2-13 UNC X 4 GR. 8 6

19 11248-008 HEX LOCK NUT 1/2-13 UNC 14

20 67591-000 SUPPORT WELDMENT 1

21 13336-001 GREASE FITTING 14

22 11934-004 ADAPTER 90° #6 1

23 63925-003 DOWN VALVE 1

24 03570-001 RETAINING PIN ASSY 1

25 67659-000 CABLE ASSY 1

26 67877.000 COUPLER 1

27 15919-006 ORIFICE 1

28 05133-000 SPRING 1

*Not Shown
