Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-90
OUTRIGGER OPTION
LX 31/41
67957-000
ITEM PART DESCRIPTION QTY
1 067844-000 OUTRIGGER SUPPORT WELDMENT 4
2 067840-000 OUTRIGGER CYL. 4
* 067840-010 SEAL KIT
3 067957-001 CONTROL MODULE ASSY 1
4 064676-001 LEVEL MOUNT ASSY 1
5 067954-000 CONTROLLER ASSY 1
6 011240-008 WASHER 1/2 STD FLAT 32
7 011246-008 NUT HEX ESNA 1/2-13 UNC 16
8 011256-020 SCREW HHC 1/2-13UNC X 2 1/2 16
9 062881-000 SWITCH BALL 4
10 063921-006 SWITCH PRESS. 4
11 066516-004 PLUG 4
12 029925-007 CONN. CABLE 4
13 011934-004 FITTING 6MBH - 6MJ 8
14 066556-001 LABEL CAUTION 4
15 066551-003 LABEL TIPPING 1
16 012798-000 TOGGLE SWITCH SPDT-MOMENTARY 4
17 067642-001 LABEL CONTROLLER 1
18 011934-001 64MBH - 4MJ 90 DEG. ELBOW 1
19 029925-000 CONN. CABLE 1
20 029939-002 NUT LOCK 1/2 NPT 1
21 067661-001 RELAY SPDT 9
22 067662-001 SOCKET RELAY 9
23 067662-005 RETAINER CLIP 18
24 020733-005 FITTING TEE 12FLX-12MJ-12MJ 1
25 014693-003 FITTING ADA 12FJ-6MJ 1
26 011941-013 FITTING 10MB-6MJ STR 1
27 029931-003 CONN FM PUSH 16-14 1/4 16
30 011252-028 SCREW HHC 1/4-20UNC X 3 1/2 2
32 011248-004 NUT HEX ESNA 1/4-20UNC 2
33 067525-000 VALVE BLOCK OUTRIGGER 1
34 063664-007 FITTING ORIFICE 1
35 011941-005 FITTING STR 6MB-6MJ 10
36 011937-003 6FJX - 6MJ 90 DEG. SWIVEL MNT. ELBOW 2
37 029601-014 TERMINAL RING 1/4" DIA. 1
38 067840-011 COUNTERBALANCE VALVE 8
39 067525-002 OUTRIGGER EXTEND / RETRACT VALVE 4
40 005469-099 WIRE 16AWG X 9 COND 95 FT
41 029452-099 WIRE 16AWG BLK 1 FT
42 029610-004 CONN. FORK #10 12-10GA. 16
43 005469-099 WIRE 16AWG. 9 COND 4 FT
44 029496-099 WIRE 16GA 2 COND 10 FT
45 062192-033 1/4 HOSE ASSY X 80 6FJX-6FJX 2
46 062192-034 1/4 HOSE ASSY X 118 6FJX-6FJX 2
47 062192-035 1/4 HOSE ASSY X 137 6FJX-6FJX 2
48 062192-036 1/4 HOSE ASSY X 176 6FJX-6FJX 2
49 062192-032 1/4 HOSE ASSY X 24 6FJX-6FJX 2
50 065234-005 1/4 HOSE ASSY X 26 4FJX-4FJX 1
*Not Shown
To Next Page
