Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-86
ITEM PART DESCRIPTION QTY
1 28800-003 PLUG CONNECTOR (FEMALE) 1
2 28800-004 PIN CONTACT (MALE) 15
3 28800-015 PLUG SEALING 16
4 28800-016 RECEPTACLE W/ CLAMP (MALE) 1
5 28800-005 SOCKET CONTACT (FEMALE) 15
6 30719-001 110 VAC BRACKET 1
7 11254-020 SCREW HHC GRD5 3/8-16UNC X 2 1/2 2
8 11240-006 WASHER 3/8 STD FLAT 4
9 11248-006 NUT HEX ESNA 3/8-16 2
REMOVABLE CONTROLLER OPTION
LX 31/41
61898-002
