Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-22
CHASSIS ASSEMBLY, LX31/41
T
WO WHEEL DRIVE
67518-000
ITEM PART DESCRIPTION QTY.
1 67715-000 CHASSIS WELDMENT 1
2 67743-000 TRUNNION (L.H.) 1
3 67742-000 TRUNNION (R.H.) 1
4 67739-000 STEERING LINK 1
5 67812-000 BUSHING, STEERING 2
6 67813-000 CONNECTING LINK 2
7 67746-000 TRUNNION PIN LOWER 2
8 67833-000 SPINDLE WELDMENT 2
9 67748-000 STEERING CLAMP 1
11 67816-000 REAR PLATE WELDMENT 1
12 67613-000 HUB, 8 BOLT ON 8" B.C. 2
* 67613-010 GREASE SEAL 1
* 67613-011 INNER CUP 1
* 67613-012 OUTER CUP 1
* 67613-013 INNER CONE 1
* 67613-014 OUTER CONE 1
* 67613-015 DUST CAP 1
* 67613-016 STUD 1
13 67600-000 TORQUE HUB 2
* 67600-010 BEARING 2
* 67600-011 SHAFT SEAL 2
* 67600-012 STUD 10
* 67600-013 O-RING 2
14 67603-000 BRAKE 2
* 67603-010 BRAKE SEAL KIT 1
15 67601-001 HYDRAULIC MOTOR 2
* 67601-010 HYD. MOT. SEAL KIT 1
16 67633-000 STEERING CYLINDER 1
* 67633-010 STEER CYL. SEAL KIT 1
17 11252-020 SCREW HHC 1/4-20 X 2 1/2 4
19 11248-004 NUT 1/4-20 HEX ESNA 4
20 67606-020 BEARING, SCISSOR PIVOT 2
21 62642-020 BUSHING 4
22 62649-020 BEARING, STEERING ROD 2
23 67606-010 BEARING 6
24 67665-000 TIRE & WHEEL ASSY FRONT RHD 1
* 67665-002 TIRE / WHEEL OPTIONAL POLLY FILL -
* 67609-001 WHEEL, 16.5 x 8.25, 8 BOLT 1
* 67610-000 TIRE 10-16.5 NHS 8 PLY 1
* 12282-001 VALVE STEM 1
25 67665-001 TIRE & WHEEL ASSY FRONT LHD 1
* 67665-003 TIRE / WHEEL OPTIONAL POLLY FILL -
* 67609-001 WHEEL, 16.5 x 8.25, 8 BOLT 1
* 67610-000 TIRE 10-16.5 NHS 8 PLY 1
* 12282-001 VALVE STEM 1
ITEM PART DESCRIPTION QTY.
26 11254-020 SCREW HHC 3/8-16 X 2 1/2 6
27 11248-006 NUT 3/8-16 HEX ESNA 6
28 11258-012 SCREW HHC 3/4-10 X 1 1/2 4
29 11238-008 WASHER 1/2 SPLIT LOCK 33
30 11256-012 SCREW HHC 1/2-13 X 1 1/2 16
31 11257-028 SCREW HHC 5/8-11 X 3 1/2 2
32 11248-008 NUT 1/2-13 HEX ESNA 10
33 11256-024 SCREW HHC 1/2-13 X 3 8
34 11848-050 PIN CLEVIS 1 X 2 3/4 1
35 67746-001 PIN STEERING LINK 2
36 11256-020 SCREW HHC 1/2-13 X 2 1/2 2
37 13315-011 RETAINING E RING 2
38 11755-012 PIN 3/16 X 1 1/2 COTTER 2
39 11935-006 FITTING 10 MB - 10 MJ 45° 2
40 11469-005 LUG NUT 9/16-18 REAR 10
41 11934-011 FITTING, 10 MB - 10 MJ 90° 4
42 11934-001 FITTING, 4 MB - 4 MJ 90° 3
43 11934-003 FITTING, 6 MB - 4 MJ 90° 2
44 12030-010 SCRW SOC HD CAP 1/2-13 X 1-1/4 8
45 11848-051 PIN CLEVIS 1 DIA. X 2 1
46 63978-000 HAND PUMP ASSY 1
47 11240-006 WASHER 3/8 STD 2
48 12877-008 VALVE, BI DIRECTIONAL RELIEF 2
49 12030-032 SCRW SOC HD CAP 1/2-13 X 4 4
50 67746-002 PIN TRUNNION UPPER 2
51 67666-000 TIRE/WHEEL ASSY REAR RHD 1
* 67666-002 TIRE / WHEEL OPTIONAL POLY FILL -
* 67605-000 WHEEL, 16.5 x 8.25, 8 BOLT 1
* 67610-000 TIRE 10-16.5 NHS 8 PLY 1
* 12282-001 VALVE STEM 1
52 67666-001 TIRE/WHEEL ASSY REAR LHD 1
* 67666-003 TIRE / WHEEL OPTIONAL POLY FILL -
* 67605-000 WHEEL, 16.5 x 8.25, 8 BOLT 1
* 67610-000 TIRE 10-16.5 NHS 8 PLY 1
* 12282-001 VALVE STEM 1
53 11941-001 FITTING 4MB-4MJ STR 1
54 11238-012 WASHER SPLIT LOCK 3/4 4
55 11782-006 THRUST BEARING 2
56 11248-010 NUT 5/8-11 HEX ESNA 2
57 67613-017 WASHER 2
58 15945-016 SPINDLE NUT 2
59 11469-006 WHEEL NUT, FRONT 16
*Not Shown
