Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-20
BASIC ASSEMBLY, LX31
F
OUR WHEEL DRIVE
67511-000
ITEM PART DESCRIPTION QTY.
1 67519-000 CHASSIS ASSEMBLY 1
2 67515-000 SCISSOR LINKAGE 1
3 67780-000 PLATFORM WELDMENT 1
4 67879-000 MOTOR COVER 2
5 11253-008 SCREW HHC 5/16 X 1 8
6 67737-001 LADDER WELDMENT 1
7 67738-000 SLIDE BLOCK 6
8 67852-000 PIN 4
9 67853-000 PIN 2
10 14996-005 WASHER, 5/16 DIA 8
11 66189-000 SPACER 1/4 4
12 67853-001 PIN 2
13 66189-004 SPACER 1/8 8
14 11256-012 SCREW HHC 1/2-13 X 1 1/2 4
15 11256-028 SCREW HHC 1/2-13 X 3 1/2 8
16 14033-032 SCREW HHC 1/2-13 X 4 GR8 8
17 11248-008 NUT 1/2-13 ESNA 16
BASIC ASSEMBLY, LX41
F
OUR WHEEL DRIVE
67513-000
ITEM PART DESCRIPTION QTY.
1 67519-000 CHASSIS ASSEMBLY 1
2 67516-000 SCISSOR LINKAGE 1
3 67780-000 PLATFORM WELDMENT 1
4 67879-000 MOTOR COVER 2
5 11253-008 SCR HHC 5/16 X 1 8
6 67737-000 LADDER WELDMENT 1
7 67738-000 SLIDE BLOCK 6
8 67852-000 PIN 4
9 67853-000 PIN 2
10 14996-005 WASHER 5/16 DIA 8
11 66189-000 SPACER 1/4 2
12 67853-001 PIN 2
13 66189-004 SPACER 1/8 8
14 11256-012 SCREW 1/2-13 X 1 1/2 4
15 11256-028 SCREW HHC 1/2-13 X 3 1/2 8
16 14033-032 SCREW HHC 1/2-13 X 4 8
17 11248-008 NUT 1/2-13 ESNA 16
