Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-28
SCISSOR LINKAGE ASSEMBLY
LX41
67516-000
ITEM PART DESCRIPTION QTY.
1 67550-000 ARM WELDMENT 1
2 67551-000 ARM WELDMENT 1
3 67552-000 ARM WELDMENT 1
4 67593-000 ARM WELDMENT 2
5 67553-000 ARM WELDMENT 1
6 67554-000 ARM WELDMENT 2
7 67555-000 ARM WELDMENT 1
8 67556-000 ARM WELDMENT 1
9 67557-000 ARM WELDMENT 1
10 67606-020 BEARING, 2" I.D. X 1 1/2" LG. 28
11 67606-030 BEARING, 3" I.D. X 1 1/2" LG. 16
12 67583-000 PIN WELDMENT 10
13 67580-000 PIN WELDMENT 8
14 67585-000 PIN WELDMENT 2
15 67635-000 LIFT CYLINDER 1
* 67635-010 SEAL KIT 1
16 67635-000 LIFT CYLINDER 1
17 14033-048 H.H.C.S. 1/2-13 UNC X 7 1/2 GR. 8 8
18 14033-032 H.H.C.S. 1/2-13 UNC X 4 1/2 GR. 8 12
19 11248-008 HEX LOCK NUT 1/2-13 UNC 20
20 67591-000 SUPPORT WELDMENT 1
21 13336-001 GREASE FITTING 20
22 11941-005 STRAIGHT ADAPTER #6 1
23 63925-005 DOWN VALVE 1
24 03570-001 RETAINING PIN ASSY 1
25 65754-004 CABLE ASSY 1
26 67877-000 COUPLER 1
27 15919-006 ORIFICE 1
28 05133-000 SPRING 1
29 11786-017 MACHINERY BUSHING, 2" ID X 14 GA. 1
30 11734-024 ROLL PIN, 3/8 DIA. X 3" LG. 1
*Not Shown
