Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-42
ITEM PART DESCRIPTION QTY.
22 67670-012 SPLIT FLANGE - HALF 3/4 2
23 67671-012 O-RING 1
24 67671-020 O-RING 1
25 14338-008 FITTING SPLIT FLANGE - 20MJ 90° 1
26 67670-020 SPLIT FLANGE - HALF 1-1/4 2
27 11255-010 SCREW HHC 7/16-14UNC X 1-1/4 4
28 11238-007 LOCK WASHER SPLIT 7/16 4
30 11252-008 SCREW HHC 1/4-20UNC X 1 3
31 11240-004 WASHER FLAT STD 1/4 6
32 11238-004 WASHER SPLIT LOCK 1/2 2
33 11248-004 NUT HEX 1/4-20 ESNA 12
34 67617-021 KTR BELL HOUSING 1
35 11256-010 SCREW HHC 1/2-13UNC X 1-1/4 2
36 11941-001 FITTING STR 4MB-4MJ 1
37 64183-000 SPACER, ENGINE 2
38 11937-001 FITTING 90° 4FJ-4MJ 1
39 11240-006 WASHER FLAT STD 3/8 2
40 63946-030 SCREW HHC M10 X 1.25 GR5 X 30MM 14
41 REF SCREW (SUPPLIED W/ AIR CLEANER) 2
42 REF SCREW MANIFOLD (SUPPLIED W/ ENGINE) 4
43 63574-099 WIRE 16 AWG BLK/WHT 3'
44 29456-099 WIRE 16 AWG YEL 2.5'
45 67672-010 SCREW HHC M8 X 1.25 X 10MM 2
46 67615-011 ELECTRIC FUEL PUMP 1
47 11261-004 SCREW HHC 1/4-28 UNF 2
48 30624-019 CHOKE ANGLE 1
49 30624-020 CHOKE ROD 1
50 30624-008 CHOKE SOLENOID BRACKET 1
51 11240-007 WASHER FLAT STD 7/16 12
52 29601-021 CONN RING 12-10 GA. 5/16D 4
53 29601-014 CONN RING 16-14 GA. 1/4D 6
54 29610-002 CONN FORK 16-14 GA. #8 6
55 29616-002 CONN FEMALE PUSH 16-14 GA. 1/4 2
56 29454-099 WIRE 16 AWG RED 2'
57 29942-099 TUBING HEAT SHRINK 1/4" 1'
58 29480-099 WIRE 10 AWG RED 2'
59 29601-039 CONN RING 10-12 GA 5/16 D 4
60 29479-099 WIRE 16 AWG WHT/BLK 4'
61 29470-099 WIRE 12 AWG RED 8'
62 29472-099 WIRE 12 AWG BLK 3'
63 67615-029 SPLINE GEAR 1
ENGINE ASSEMBLY, LX31/41
K
UBOTA GAS
67523-001
ITEM PART DESCRIPTION QTY.
1 67615-000 ENGINE, KUBOTA GAS 1
* 64505-011 OIL FILTER ELEMENT 1
* 64505-009 FUEL FILTER ELEMENT 1
* 64505-007 CARBURETOR 1
* 67615-013 RADIATOR 1
* 67615-014 RADIATOR CAP 1
* 67615-015 WATER PUMP 1
* 67615-016 THERMOSTAT 1
* 67615-019 FAN BELT 1
* 64505-002 SPARK PLUG 1
* 67615-020 SPARK PLUG WIRE #1 1
* 67615-021 SPARK PLUG WIRE #2 1
* 67615-022 SPARK PLUG WIRE #3 1
* 67615-023 COIL WIRE 1
* 67615-024 DISTRIBUTOR CAP 1
* 67615-025 ROTOR 1
* 67615-026 IGNITION MODULE 1
* 67615-028 ALTERNATOR 1
* 64505-004 VOLTAGE REGULATOR 1
* 67615-030 STARTER 1
* 64505-005 OIL PRESSURE SWITCH 1
* 67615-006 WG750 ENGINE PARTS MANUAL 1
* 67615-007 WG750 ENGINE SERVICE MANUAL 1
2 67608-000 PUMP, VARIABLE DISPLACEMENT 1
3 63941-000 SOLENOID, THROTTLE, CHOKE 2
4 12733-099 HOSE, FUEL LINE 4.5'
5 20541-001 HOSE CLAMP 6
6 20331-000 FUEL FILTER, INLINE 1
7 27972-000 SOLENOID, STARTER RELAY 1
8 11252-006 SCREW HHC 1/4-20 X 3/4 12
9 67874-000 BRACKET, ENGINE MOUNT GAS 2
10 64505-008 AIR CLEANER ELEMENT 1
11 67872-000 BRACKET, AIR CLEANER 1
12 11254-008 SCREW HHC 3/8-16 X 1 2
13 64177-004 WELDMENT, MUFFLER SPACER 1
14 67615-027 COIL, IGNITION 1
16 64423-000 INLINE SWIVEL - 1/4 1
17 11760-004 ROD END BEARING - 1/4-28 1
18 11934-008 FITTING 8MB-8MJ 90° 1
19 67871-000 BRACKET, SOLENOID 1
20 11254-010 SCREW HHC 3/8-16UNC X 1-1/4 4
21 11238-006 LOCKWASHER, SPLIT 3/8 6
*Not Shown
