Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-48
VALVE BLOCK ASSEMBLY, LX31/41
T
WO WHEEL DRIVE
67524-000
ITEM PART DESCRIPTION QTY.
1 67821-000 VALVE BLOCK 1
2 60390-007 VALVE, STEERING RELIEF 2
3 63928-001 VALVE, STEERING 1
4 63955-010 PLUG, CAVITY #8 - 2 WAY 1
5 63955-009 PLUG, CAVITY #8 - 3 WAY 1
6 67621-000 VALVE, PROPORTIONAL 1
7 60390-016 VALVE, LIFT RELIEF 1
8 67622-000 VALVE, SOL. 2 POS 3 WAY 5
9 14862-001 VALVE, COUNTERBALANCE 2
10 67623-000 VALVE, FLOW DIVIDER/COMBINER 1
11 11941-005 ADAPTER, #6 MB - #6 MJ 2
12 11941-009 ADAPTER, #8 MB - #6 MJ 1
13 11941-015 ADAPTER, #10 MB - #10 MJ 4
14 11941-020 ADAPTER, #12 MB - #12 MJ 2
15 11934-004 ADAPTER, 90° #6 MB - #6 MJ 2
16 15961-004 ADAPTER, TEE #4MB-#4MJ-#4MJ 1
17 05133-000 SPRING 1
18 15919-000 ORIFICE 1
19 67667-000 ORIFICE .059 DIA. (1.5MM) 1
20 67619-000 STACK PLATE, SHUTTLE VALVE 1
21 63965-001 PLUG, GUAGE PORT 3
22 20021-004 PLUG, #4 MB 1
23 11979-002 O-RING, #2 MB 1
24 11939-000 ADAPTER, #2 MJ - #2 MP 1
25 11929-001 COUPLER, #2 FP - #2 FP 1
26 20733-005 ADAPTER, TEE #12FJX-#12MJ-#12MJ 1
27 13968-005 ADAPTER 90°, #12FJX-#12MP 1
28 67618-004 CHECK VALVE 1
29 14412-022 SCRW SOC HD #10-24UNC X 2-3/4 4
