Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-52
CONTROL BOX ASSEMBLY, LX31/41
T
WO WHEEL DRIVE, GAS
67527-002
ITEM PART DESCRIPTION QTY.
1 67825-000 ENCLOSURE 1
2 67529-003 PANEL ASSEMBLY, DUAL FUEL 1
3 64417-001 MOUNTING LATCH 9
4 64443-001 CONTACT BLOCK, N.O. 7
5 64443-002 CONTACT BLOCK, N.C. 4
6 67652-000 PUSH BUTTON, GREEN 2
7 67653-000 PUSH BUTTON, RED 2
8 67654-000 PUSH BUTTON, BLK. 1
9 63778-000 ALARM, DUAL FUNCTION 1
10 29868-007 CIRCUIT BREAKER, 15 AMP. 2
11 64446-003 PUSH BUTTON, MUSHROOM, RED 1
12 67656-000 PUSH BUTTON, ALTERNATE ACTION, BLK. 1
13 67657-000 SELECTOR, 2 POS. 2
14 11252-006 SCRW, HHC 1/4-20UNC X 3/4 2
15 11248-006 NUT, SELF LOCKING, 3/8-16 4
16 14996-006 FLATWASHER, 3/8" 4
17 29925-011 STRAIN RELIEF, 3/4" 2
18 29925-000 STRAIN RELIEF, 1/2" 2
19 29939-003 CONDUIT NUT, 3/4" 2
20 29939-002 CONDUIT NUT, 1/2" 2
21 11248-004 LOCKNUT, 1/4-20UNC ESNA 2
22 14996-004 WASHER, 1/4" SAE 2
23 66516-000 PLUG, HOLE 2.09 DIA. 1
24 29825-002 DIODE 3 AMP 7
25 29610-002 TERMINAL #8 FORK 37
26 29610-003 TERMINAL #6 FORK 32
27 29731-005 RESISTOR, 10 OHM 1
28 29496-099 CABLE 2 COND 16GA 25'
29 29447-099 CABLE 3 COND 16GA 5'
30 05491-099 WIRE 16GA GRN/BLK 1'
31 29450-099 WIRE 16GA BLU 8'
32 29451-099 WIRE 16GA WHT 7'
33 29452-099 WIRE 16GA BLK 10'
34 29456-099 WIRE 16GA YEL 2'
35 29457-099 WIRE 16GA GRN 1'
36 29459-099 WIRE 16GA BLU/WHT 5'
37 29475-099 WIRE 16GA BLU/BLK 6'
38 29477-099 WIRE 16GA ORN/BLK 4'
39 29478-099 WIRE 16GA RED/BLK 4'
40 29482-099 WIRE 16GA GRN/WHT 3'
41 29483-099 WIRE 16GA RED/WHT 2'
42 29620-002 CONN 16GA BUTT 2
43 64602-029 PLUG 15/16 1
CONTROL BOX ASSEMBLY, LX31/41
T
WO WHEEL DRIVE, DIESEL
67527-003
ITEM PART DESCRIPTION QTY.
1 67825-000 ENCLOSURE 1
2 67529-003 PANEL ASSEMBLY, DUAL FUEL 1
3 64417-001 MOUNTING LATCH 8
4 64443-001 CONTACT BLOCK, N.O. 7
5 64443-002 CONTACT BLOCK, N.C. 3
6 67652-000 PUSH BUTTON, GREEN 2
7 67653-000 PUSH BUTTON, RED 2
8 67654-000 PUSH BUTTON, BLK. 1
9 63778-000 ALARM, DUAL FUNCTION 1
10 29868-007 CIRCUIT BREAKER, 15 AMP. 2
11 64446-003 PUSH BUTTON, MUSHROOM, RED 1
12 67656-000 PUSH BUTTON, ALTERNATE ACTION, BLK. 1
13 67657-000 SELECTOR, 2 POS. 1
14 11252-006 SCRW, HHC 1/4-20UNC X 3/4 2
15 11248-006 NUT, SELF LOCKING, 3/8-16 4
16 14996-006 FLATWASHER, 3/8" 4
17 29925-011 STRAIN RELIEF, 3/4" 2
18 29925-000 STRAIN RELIEF, 1/2" 2
19 29939-003 CONDUIT NUT, 3/4" 2
20 29939-002 CONDUIT NUT, 1/2" 2
21 11248-004 LOCKNUT, 1/4-20UNC ESNA 2
22 14996-004 WASHER, 1/4" SAE 2
23 66516-000 PLUG, HOLE 2.09 DIA. 1
24 29825-002 DIODE 3 AMP 7
25 29610-002 TERMINAL #8 FORK 35
26 29610-003 TERMINAL #6 FORK 31
27 29731-005 RESISTOR, 10 OHM 1
28 29496-099 CABLE 2 COND 16GA 25'
29 29447-099 CABLE 3 COND 16GA 5'
30 05491-099 WIRE 16GA GRN/BLK 1'
31 29450-099 WIRE 16GA BLU 8'
32 29451-099 WIRE 16GA WHT 6'
33 29452-099 WIRE 16GA BLK 6'
34 29456-099 WIRE 16GA YEL 2'
35 29457-099 WIRE 16GA GRN 1'
36 29459-099 WIRE 16GA BLU/WHT 5'
37 29475-099 WIRE 16GA BLU/BLK 4'
38 29477-099 WIRE 16GA ORN/BLK 4'
39 29478-099 WIRE 16GA RED/BLK 4'
40 29482-099 WIRE 16GA GRN/WHT 2'
41 29483-099 WIRE 16GA RED/WHT 2'
42 29620-002 CONN 16GA BUTT 2
43 64602-029 PLUG 15/16 2
