Illustrated Parts Breakdown

7.2

SectionSection

Section

LX31/41 Work Platform7-72

HOSE ASSEMBLY, LX31/41

WO WHEEL DRIVE

67533-000

ITEM PART DESCRIPTION QTY.

1 67680-027 1-1/4 HOSE ASSY X 27 20FJX-20FJX 90° 1

2 67857-334 3/8 HOSE ASSY X 334 6FJX-6FJX 90° 1

3 67676-131 3/4 HOSE ASSY X 131 12FJX-12FJX 90° 1

4 67682-026 1/2 HOSE ASSY X 26 8FJX-8FJX 90° 1

5 67858-108 3/4 HOSE ASSY X 108 12FJX-12FJX 1

6 65234-096 1/4 HOSE ASSY X 96 4FJX-4FJX 1

7 67683-085 3/8 HOSE ASSY X 85 6FJX-6FJX45° 2

8 67677-144 5/8 HOSE ASSY X 144 10FJX-10FJX90° 2

9 67684-200 3/8 HOSE ASSY X 200 6FJX-6FJX90° 1

10 67677-112 5/8 HOSE ASSY X 112 10FJX-10FJX90° 2

11 65234-152 1/4 HOSE ASSY X 152 4FJX-4FJX 1

12 65234-014 1/4 HOSE ASSY X 46.5 4FJX-4FJX 1

13 65234-032 1/4 HOSE ASSY X 32 4FJX-4FJX 1

14 65234-001 1/4 HOSE ASSY X 20 4FJX-4FJX 1

15 67685-030 1/2 HOSE ASSY X 30 12MP-10FJX 1

16 67686-022 1/8 HOSE ASSY X 22 2MP-4FJX 1

17 20032-001 FITTING 4MJ-4MJ TEE REF

Upright LX31 Service & Parts Manual
