Illustrated Parts Breakdown

7.2

SectionSection

Section

LX31/41 Work Platform7-74

HOSE ASSEMBLY, LX31/41

OUR WHEEL DRIVE

67533-001

ITEM PART DESCRIPTION QTY.

1 67680-027 1-1/4 HOSE ASSY X 27 20FJX-20FJX 90° 1

2 62192-009 1/4 HOSE ASSY X 65 4FJX-4FJX 1

3 67857-334 3/8 HOSE ASSY X 334 6FJX-6FJX90° 1

4 67676-131 3/4 HOSE ASSY X 131 12FJX-12FJX 90° 1

5 67681-152 1/4 HOSE ASSY X 152 4FJX-4FJX 90° 1

6 67682-026 1/2 HOSE ASSY X 26 8FJX-8FJX 90° 1

7 67858-108 3/4 HOSE ASSY X 108 12FJX-12FJX 1

8 65234-096 1/4 HOSE ASSY X 96 4FJX-4FJX 1

9 67679-044 1/2 HOSE ASSY X 44 10FJX-8FJX 45° 4

10 67758-099 HOSE GUARD - NYLON 1

11 67681-080 1/4 HOSE ASSY X 80 4FJX-4FJX 90° 1

12 67918-008 1/8 HOSE ASSY X 8 4FJX-4FJX 2

13 67681-100 1/4 HOSE ASSY X 100 4FJX-4FJX 90° 1

14 67681-115 1/4 HOSE ASSY X 115 4FJX-4FJX 90° 1

15 67683-085 3/8 HOSE ASSY X 85 6FJX-6FJX 45° 2

16 67677-090 5/8 HOSE ASSY X 90 10FJX-10FJX 90° 1

17 67677-055 5/8 HOSE ASSY X 55 10FJX-10FJX 90° 1

18 67677-144 5/8 HOSE ASSY X 144 10FJX-10FX J90° 1

19 67684-200 3/8 HOSE ASSY X 200 6FJX-6FJX 90° 1

20 67677-112 5/8 HOSE ASSY X 112 10FJX-10FJX 90° 1

21 65234-152 1/4 HOSE ASSY X 152 4FJX-4FJX 1

22 65234-014 1/4 HOSE ASSY X 46.5 4FJX-4FJX 1

23 67687-061 5/8 HOSE ASSY X 61 10FJX90-10FJX90 1

24 65234-032 1/4 HOSE ASSY X 32 4FJX-4FJX 1

25 65234-001 1/4 HOSE ASSY X 20 4FJX-4FJX 1

26 67687-100 5/8 HOSE ASSY X 100 10FJX90-10FJX90 1

27 67685-120 1/2 HOSE ASSY X 120 12MP-10FJX 1

28 67686-022 1/8 HOSE ASSY X 22 2MP-4FJX 1

29 20032-001 FITTING 4MJ-4MJ TEE 1
