Upright LX31 Service & Parts Manual

Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-76
LABEL KIT, LX31
F
OUR WHEEL DRIVE
GAS 67532-002, DIESEL 67532-003
ITEM PART DESCRIPTION
GAS DIESEL
QTY. QTY.
1 10076-000 MANUAL CASE 1 1
2 10076-001 LABEL-ATTENTION 1 1
3 67903-000 USER MANUAL LX-SERIES 1 1
4 60197-000 LABEL-HYD. FLUID 1 1
5 61205-000 NAME PLATE 1 1
6 61220-001 LABEL-ANSI 1 1
7 60577-000 ANSI MANUAL 1 1
8
64166-000 LABEL-UNLEADED FUEL 1
27898-000 LABEL-DIESEL FUEL 1
9 66552-000 LABEL-WARNING BATTERY 1 1
10 64444-000 LABEL-USA 4 4
11 67642-000 LABEL-CONTROLLER 1 1
12 67638-000 LABEL-MOTOR CONTROLS 1 1
13 67639-000 LABEL-PLATFORM CONTROLS 1 1
14 66550-009 LABEL-DANGER 1 1
15 66551-002 LABEL-CAUTION 1 1
16 66551-003 LABEL-DANGER TIPPING 1 1
17 66554-000 LABEL-READ 1 1
18 66555-000 LABEL-DO NOT ADJUST 1 1
19 63423-000 LABEL-BRAKE RELEASE 1 1
20 66562-000 LABEL-TIRE PSI 50 1 1
21 61515-000 LABEL-LIFT HERE 1 1
22 66568-000 LABEL-WARNING 1 1
23 66558-000 LABEL, EMERG. LOWERING 2 2
24 66557-010 LABEL-MAX LOAD 2 2
25 61683-005 LABEL-UPRIGHT 4 1/2 3 3
26 61683-007 LABEL-UPRIGHT 5 1/2 4 4
27 67644-006 LABEL-LX31 4WD 5 5
28 67644-005 LABEL LX31 4WD 2 2
29 11248-004 NUT HEX ESNA 1/4-20UNC 4 4
30 11525-008 SCREW HHC 1/4-20UNC X 1 4 4
31 65368-000 DRIVE SCREW 4 4
32 60830-000 SAFETY WALK 4 4
33 66561-001 LABEL, MAINT. BRACE 1 1
34 60086-000 SAFETY WALK 20 X 32 12 12
LABEL KIT, LX31
T
WO WHEEL DRIVE
GAS 67532-000, DIESEL 67532-001
ITEM PART DESCRIPTION
GAS DIESEL
QTY. QTY.
1 10076-000 MANUAL CASE 1 1
2 10076-001 LABEL-ATTENTION 1 1
3 67903-000 USER MANUAL LX-SERIES 1 1
4 60197-000 LABEL-HYD. FLUID 1 1
5 61205-000 NAME PLATE 1 1
6 61220-001 LABEL-ANSI 1 1
7 60577-000 ANSI MANUAL 1 1
8
64166-000 LABEL-UNLEADED FUEL 1
27898-000 LABEL-DIESEL FUEL 1
9 66552-000 LABEL-WARNING BATTERY 1 1
10 64444-000 LABEL-USA 4 4
11 67642-000 LABEL-CONTROLLER 1 1
12 67638-000 LABEL-MOTOR CONTROLS 1 1
13 67639-000 LABEL-PLATFORM CONTROLS 1 1
14 66550-009 LABEL-DANGER 11
15 66551-002 LABEL-CAUTION 1 1
16 66551-003 LABEL-DANGER TIPPING 1 1
17 66554-000 LABEL-READ 1 1
18 66555-000 LABEL-DO NOT ADJUST 1 1
19 63423-000 LABEL-BRAKE RELEASE 1 1
20 66562-000 LABEL-TIRE PSI 50 1 1
21 61515-000 LABEL-LIFT HERE 1 1
22 66568-000 LABEL-WARNING 1 1
23 66558-000 LABEL, EMERG. LOWERING 2 2
24 66557-010 LABEL-MAX LOAD 2 2
25 61683-005 LABEL-UPRIGHT 4 1/2 3 3
26 61683-007 LABEL-UPRIGHT 5 1/2 4 4
27 67644-002 LABEL-LX31 2WD 5 5
28 67644-001 LABEL-LX31 2WD 2 2
29 11248-004 NUT HEX ESNA 1/4-20UNC 4 4
30 11525-008 SCREW HHC 1/4-20UNC X 1 4 4
31 65368-000 DRIVE SCREW 4 4
32 60830-000 SAFETY WALK 4 4
33 66561-001 LABEL, MAINT. BRACE 1 1
34 60086-000 SAFETY WALK 20 X 32 12 12
