Illustrated Parts Breakdown
7.2
SectionSection
SectionSection
Section
LX31/41 Work Platform7-2
FINAL ASSEMBLY, LX31
T
WO WHEEL DRIVE GAS
67501-000
ITEM PART DESCRIPTION QTY.
1 67510-000 BASIC ASSY 1
2 67528-000 CONTROLLER ASSY 1
3 67536-000 CONTROL CABLE ASSY 1
4 67532-000 LABEL-KIT 1
* 67533-000 HOSE-KIT 1
6 67530-002 GUARDRAIL ASSY 1
7 67522-001 POWER MODULE 1
8 67521-000 CONTROL MODULE 1
9 29620-002 CONN. BUTT 16-14 GA. 8
10 26551-005 RIVET 1/8 X 1/4 GRIP 8
11 67913-000 ALUM. SW. PAD 2
12 67692-000 CLIP, CABLE RETAINER 4
13 29480-099 WIRE, 10GA STRD RED 10'
14 29945-013 LEVEL SENSOR 1
15 11252-006 SCRW, 1/4-20 X 3/4 2
16 11248-004 LOCKNUT, 1/4-20 UNC 2
17 65373-005 MAGNET 2
18 65373-006 SWITCH 2
19 62125-016 BATTERY CABLE ASSY 1
20 62125-002 BATTERY CABLE ASSY 1
21 29616-003 TERMINAL, FEMALE PUSH 1
22 29616-002 TERMINAL, FEMALE PUSH 4
23 29601-019 TERMINAL, RING 1
24 29610-002 TERMINAL, FORK 5
25 29601-011 TERMINAL, RING 3
26 29448-099 WIRE, 7 CONDUCTOR 10'
27 67863-000 SWITCH MOUNT PLATE 1
28 14996-004 WASHER 1/4" 4
FINAL ASSEMBLY, LX41
T
WO WHEEL DRIVE GAS
67541-000
ITEM PART DESCRIPTION QTY.
1 67512-000 BASIC ASSY 1
2 67528-000 CONTROLLER ASSY 1
3 67536-000 CONTROL CABLE ASSY 1
4 67532-000 LABEL KIT 1
* 67533-000 HOSE-KIT 1
6 67530-002 GUARDRAIL ASSY 1
7 67522-001 POWER MODULE 1
8 67521-000 CONTROL MODULE 1
9 29620-002 CONN. BUTT 16-14 GA. 8
10 26551-005 RIVET 1/8 X 1/4 GRIP 8
11 67913-000 ALUM. SW. PAD 2
12 67692-000 CLIP, CABLE RETAINER 8
13 29480-099 WIRE, 10GA STRD RED 10'
14 29945-013 LEVEL SENSOR 1
15 11252-006 SCRW, 1/4-20 X 3/4 2
16 11248-004 LOCKNUT, 1/4-20 UNC 2
17 65373-005 MAGNET 2
18 65373-006 SWITCH 2
19 62125-016 BATTERY CABLE ASSY 1
20 62125-002 BATTERY CABLE ASSY 1
21 29616-003 TERMINAL, FEMALE PUSH 1
22 29616-002 TERMINAL, FEMALE PUSH 4
23 29601-019 TERMINAL, RING 1
24 29610-002 TERMINAL, FORK 7
25 29601-011 TERMINAL, RING 3
26 29448-099 WIRE, 7 CONDUCTOR 10'
27 67863-000 SWITCH MOUNT PLATE 1
28 14996-004 WASHER 1/4" 4
*Not Shown
