SB80 Work Platform - European 6-83
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
M
ASTER
C
YLINDER
A
SSEMBLY
,
SB80
102336-000
ITEM PART NO. DESCRIPTION QTY.
1 102255-000 CYLINDER, MASTER 1
* 102255-010 SEAL KIT -
* 102255-003 BUSHING (CYLINDER END) 2
* 102255-004 BUSHING (ROD END) 1
* 102255-005 COUNTERBALANCE VALVE 1
2 100432-002 FITTING, STR ADAPTER 4MB-4MF OR 2
3 100434-002 FITTING, 90° ADAPTER 4MB-4MFOR 2
*Not Shown
