Upright SB80 - Page 170

To Next Page

To Previous Page

6-86 SB80 Work Platform - European

LLUSTRATED

ARTS

REAKDOWN

Section

6.1

YLINDER

SSEMBLY

SB80

102339-000

ITEM PA RT NO. DESCRIPTION QTY.

1 102251-000 JIB CYLINDER 1

* 102251-010 SEAL KIT -

* 102251-003 BUSHING 4

2 100432-002 FITTING, STR. ADAPTER 4MB-4MFOR 2

3 102251-004 COUNTERBALANCE VALVE 2

*Not Shown
