Part Names
1-7
1
33 Main Power Switch
34 Cassette Heater Switch
35 Network Interface Connector
36 USB Interface Connector (A2)
37 USB Port (B1)
38 Option Interface Slot 1
39 Option Interface Slot 2
34
33
36
37
38
35 39
