Preparation before Use
2-29
2
Loading Paper in the Cassettes
The standard cassettes
The 2 standard cassettes will each hold plain paper, recycled paper or color paper.
Cassette 1 and 2 hold up to 500 sheets of plain paper (80 g/m
2
) (or up to 550 sheets of 64 g/m
2
plain paper).
The following paper sizes are supported: A3, B4, A4, A4-R, B5, B5-R, A5-R, Ledger, Legal, Oficio II, Letter,
Letter-R, Statement-R, Folio, 8K, 16K, 16K-R and 216 × 340 mm.
1 Pull the cassette out toward you until it stops.
2 Squeeze the ends of the bottom of the paper length
guide and move the guide to fit the length of the
paper.
IMPORTANT:
• When using media types other than plain paper (such as recycled or colored paper), always specify the
media type and paper weight settings. (Refer to Specifying Paper Size and Media Type for the
Cassettes on page 2-36, Media Type Setting on page 9-8.)
The cassettes can hold paper with weights between 60 and 256 g/m
2
. If you are using a paper weight
between 106 and 256 g/m
2
, set the media type to Thick and set the weight of the paper you are using.
• If the size of the paper being loaded is Oficio II, 8K, 16K,16K-R, or 216×340 mm, be sure to set the paper
size. (Refer to Specifying Paper Size and Media Type for the Cassettes on page 2-36, Media Type
Setting on page 9-8.)
• If you wish to use 330 × 210 mm to 356 × 220 mm paper, contact a service technician.
NOTE: Do not pull out more than one cassette at a
time.
NOTE: Paper sizes are marked on the cassette.
NOTE:
When using 11 × 17" (ledger) paper, lay the paper length guide down flat.
To Next Page
