DE35-ST Operating Instructions
D292469I 115
1.1, 1.5 & 2.0 Diameter Eject Heads
Note for piston and hex style eject heads:
Based on piston design, a set screw may secure more than one needle in the piston and
can vary by eject head. The user should consult the eject head needle configuration/set-
up documentation that is provided with those eject heads.
Stainless
Steel
Piston style EJA
Eject Head Body
Adapter / Vacuum Gallery
Adapter Set Screws
Eject Needles
Springs
Eject head body
Body O-ring
Brass Piston
Screw(s)
