V2 AYROS User Manual

ENGLISH
- 54 -
PARAMETER VALUE DESCRIPTION DEFAULT MEMO
Co.tE
Test of the safety edges
This menu allows setting the method of control of the safety edges
working
no
no
Test disabled
rESi
Test enabled for conductive rubber safety edges
Foto
Test enabled for optical safety edges
S.EnC
Encoder sensitivity
0
0 - 7
This menu allows the sensitivity of the rate sensor to be adjusted.
A decreased rate below the set threshold indicates the presence of an
obstacle.
If set to 0 the obstacle is only detected when the gate is stopped.
When the sensor intervenes, the gate stops and is operated in the reverse
direction for 3 seconds to remove the obstacle.
The next start command restarts the movement in the previous direction
i.Adi
Enabling the ADI device
This menu makes it possible to enable operation of the device connected
to the ADI connector.
PLEASE NOTE: selecting Si and pressing MENU accesses the
configuration menu for the device connected to the ADI connector.
This menu is managed by the device itself and is different for each device.
Please refer to the manual for the device.
If the Si option is selected, but no device is connected, the display will
show a series of dotted lines.
Exiting the ADI device configuration menu returns to the i.Adi option
no
no
Interface disabled, any signals will be ignored
Si
Interface enabled
Ev.di
Display of the events
If this function is enabled, every time that an event changes the normal
operation of the gate (coming into action of a safety, control by user, etc.)
the display shows a message indicating the cause.
Si
Si
Function activated
no
Function deactivated
Ev.M
Storage level of the events
3
0 - 5
The events are stored in the list of events for diagnosis according to the
set value in this menu:
0 Only the reset and the programming operations
1 Even the errors detected by the various tests (Err2, Err3, etc.).
2 Even the events that change the normal operation of the gate (coming
into action of a safety, control by user, etc.).
3 Even the safeties that have prevented the activation operation cycle
(stop, etc.).
4 Even the controls that have activated an operation cycle (start, etc.).
5 Even the automatic actions of the unit (En.SA and t.inA)
FinE
End of Programming
This menu allows to finish the programming (both default and
personalized) saving the modified data into memory
no
no
Do not quit the programming
Si
End of programming
