Vacon 100 flow User Manual

7
vacon • 32 Common Industrial Objects implemented by vacon® 100 family
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
Instance Attribute “Configuration Capability”
This attribute presents the capability flags (that is, the support for the optional network
configuration capability) of the TCP/IP network interface.
Table 16. Status Bit Descriptions
Bit(s) Called Definition
0-3
Interface Con-
figuration Status
Indicates the
status of the
interface config-
uration attribute
Value Definition
0
The Interface Configuration
Attribute has not been configured
1
The Interface Configuration
Attribute contains valid configura-
tion obtained from BOOTP, DHCP
or non-volatile storage.
2
The IP address member of the
Interface Configuration Attribute
contains valid configuration,
obtained from hardware settings
3-15 Reserved for future use
4Mcast Pending
Indicates a pending configuration change in the TTL Value and/
or Mcast Config attributes.
5
Interface Con-
figuration Pend-
ing
Indicates a pending configuration change in the Interface Con-
figuration attribute.
6AcdStatus
Set(1) Address Conflict Detected, Clear(0) No Address Conflict
Detected
7-31 Reserved Always zero
Table 17. Configuration capability bit descriptions
Bit(s) Called Definition
0BOOTP ClientSupports BOOTP (FALSE)
1DNS Client
Supports capable of resolving DNS names
(FALSE)
2 DHCP Client Supports DHCP (TRUE)
3 DHCP-DNS Update Always zero
4 Configuration Settable TRUE, if configuration settable
5 Hardware Configurable
Configuration can be obtained from hardware
settings (FALSE)
6
Interface Configuration Change
Requires Reset
Configuration change results in reset (FALSE)
7 AcdCapable Supports ACD (TRUE)
8-31 Reserved Reserved, always zero

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
