Vacon 100 flow User Manual

7
vacon • 42 Common Industrial Objects implemented by vacon® 100 family
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
7.2.2.1 Instance Attributes
Instance Attribute “MotorType”
The VACON® 100 Family AC drives support values 3 (Permanent Magnet Synchronous Motor) and 7
(Squirrel Cage Induction Motor).
Instance Attribute “RatedCurrent”
This attribute allows reading and writing of the motor rated current. The unit of the attribute is 100
milliamperes.
Instance Attribute “RatedVoltage”
This attribute allows reading and writing of the motor rated voltage. The unit of the attribute is 1 volt.
Instance Attribute “RatedFreq”
This attribute allows reading and writing of the motor rated electrical frequency. The unit of the
attribute is 1 hertz.
Class
Attributes
Id Access rule Name Datatype Description
-- - - -
Class Ser-
vices
Id Name Description
-- -
Instance
Attributes
Id Access rule Name Datatype Description
3 Get/Set MotorType USINT Motor type
6 Get/Set RatedCurrent UINT
Rated Stator Current
Units: [100mA]
7 Get/Set RatedVoltage UINT
Rated Base Voltage
Units: [V]
9 Get/Set RatedFreq UINT
Rated Electrical Fre-
quency Units: [Hz]
12
d
0C
h
Get PoleCount UINT
Number of poles in the
motor.
15
d
0F
h
Get/Set Base Speed UINT
Nominal speed at rated
frequency from name-
plate Units: [RPM]
Instance
Services
Id Name Description
14
d
0E
h
Get_Attribute_Single Used to read single attribute value.
16
d
10
h
Set_Attribute_Single Used to write a single attribute value.
Table 29. Motor data object

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
