Vacon 100 flow User Manual

Common Industrial Objects implemented by vacon® 100 family vacon • 59
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
7
7.3.4.1 Changes from revision 1 to revision 2
The attributes FaultCode and FaultDay were changed from 8 bit to 16 bit.
7.3.4.2
Class Attributes
Class Attribute “Revision”
This attribute presents the revision of the Fault History Object which is implemented by the device.
The current revision is 2.
Class Attribute “Max Instance”
This attribute presents the maximum number of instances that can exist of the Fault History Object
in the device. The maximum value is 40.
Class Attribute “Number of Instances”
This attribute presents the number of instances that currently exist of the Fault History Object in the
device.
Class Ser-
vices
Id Name Description
1 Get_Attributes_All
Returns content of all (implemented)
attributes in the class.
5 Reset Reset fault history
14
d
0E
h
Get_Attribute_Single Used to read single attribute value.
Instance
Attributes
Id Access rule Name Datatype Description
1 Get FaultCode UINT Fault code
2Get FaultIDUINTFault ID
3 Get FaultYear UINT Fault date: Year
4 Get FaultMonth USINT Fault date: Month
5Get FaultDayUINTFault date: Day
6Get
FaultMillisAfter
Midnight
UDINT
Fault date: Time, millisec-
onds after midnight
Instance
Services
Id Name Description
1 Get_Attributes_All
Returns content of all (implemented)
attributes in the instance
14
d
0E
h
Get_Attribute_Single Used to read single attribute value
Table 51. Fault history object

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
