Vacon NX User Manual

5
vacon • 64 Installation
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Figure 30. Pressure loss, CH7x
The liquid carrying hoses from the network to the cooling elements of the drive must not be
electrically conductive. Risk of electrical shock and device damage! To avoid electrochemical
corrosion, it is necessary to add an inhibitor (e.g. Cortec VpCI-649l in the cooling liquid.
The following main line hose materials are allowed for a liquid cooled drive including an aluminum
heatsink:
The following main line hose materials are allowed for a liquid cooled drive including a nickel coated
aluminum heatsink:
Table 23. Pressure losses; CH7x
CH7x (16) with standard 1.5m hoses and optional fast connectors TEMA
Volume
flow
rate (l/
min)
Pressure
loss;
Tema,
inflow
(bar)
Pressure
loss;
inflow
hose (bar)
Pressure
loss;
element
(bar)
Pressure
loss;
outflow
hose: (bar)
Pressure
loss; Tema,
outflow
(bar)
Pressure
loss total
(inflow
hose,
element
and outflow
hose) (bar)
Pressure
loss total
(Tema,
inflow and
outflow
hoses and
element)
(bar)
40.0 0.61 0.30 0.28 0.28 0.50 0.87 1.97
30.0 0.31 0.17 0.17 0.16 0.26 0.50 1.07
20.0 0.11 0.09 0.08 0.07 0.10 0.24 0.44
• plastic (PVC) • aluminium
• rubber (EPDM & NBR only) • other stainless and acid-proof materials
• plastic (PVC) • aluminium
• rubber (EPDM & NBR only) • brass
• copper • other stainless and acid-proof material
CH7, pressure loss
10,0
15,0
20,0
25,0
30,0
35,0
40,0
45,0
0,00 0,50 1,00 1,50 2,00 2,50
Pressure loss, bar
Volume flow rate
Pressure loss; element (SEE-
PEJ)
Pressure loss; outflow hose;
(PEJ-PLJ)
Pressure loss; inflow hose (SEL-
SEE)
Pressure loss; Tema, inflow
(SET-SEL)
Pressure loss; Tema, outflow
(PLJ-PTJ)
Pressure loss total (inflow hose,
element and outflow hose)
Pressure loss total (Tema, inflow
and outflow hoses, element)
11338_uk

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
