vacon • 204 Brake chopper unit (NXB)
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
12.5 BCU power ratings
12.5.1 VACON
®
NXB; DC voltage 460–800 V
For dimensions of BCU units, see Table 14.
NOTE! The rated currents in given ambient (+50 °C) and coolant (+30°) temperatures are achieved
only when the switching frequency is equal to or less than the factory default.
NOTE! Braking power: P
brake
= 2*U
brake
2
/ R
brake
NOTE! Max input DC current: I
in_max
= P
brake_max
/ U
brake
Table 98. Power ratings of VACON
®
NXB, supply voltage 460–800 Vdc
Braking voltage 460-800 VDC
NXB type
Loadability Braking capacity
Chassis
BCU rated
cont. braking
current, I
br
[A]
Rated min
resistance
at 800 VDC
[
Ω]
Rated min
resistance
at 600 VDC
[Ω]
Rated
max input
current
[Adc]
Rated cont.
braking
power
2*R at
800 VDC
[kW]
*
*. 800 VDC equals U
brake
at 500 VAC
Rated cont.
braking
power
2*R at
600 VDC
[kW]
**
**. 600 VDC equals U
brake
at 380 VAC
NXB_0031 5 2*31 25.7 19.5 62 49 37 CH3
NXB_0061 5 2*61 13.1 9.9 122 97 73 CH3
NXB_0087 5 2*87 9.2 7.0 174 138 105 CH4
NXB_0105 5 2*105 7.6 5.8 210 167 127 CH4
NXB_0140 5 2*140 5.7 4.3 280 223 169 CH4
NXB_0168 5 2*168 4.7 3.6 336 267 203 CH5
NXB_0205 5 2*205 3.9 3.0 410 326 248 CH5
NXB_0261 5 2*261 3.1 2.3 522 415 316 CH5
NXB_0300 5 2*300 2.7 2.0 600 477 363 CH61
NXB_0385 5 2*385 2.1 1.6 770 613 466 CH61
NXB_0460 5 2*460 1.7 1.3 920 732 556 CH62
NXB_0520 5 2*520 1.5 1.2 1040 828 629 CH62
NXB_0590 5 2*590 1.4 1.1 1180 939 714 CH62
NXB_0650 5 2*650 1.2 1.0 1300 1035 786 CH62
NXB_0730 5 2*730 1.1 0.9 1460 1162 833 CH62
