vacon • 208 Brake chopper unit (NXB)
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
12.6.2 Braking power and resistance, mains voltage 380–500 Vac/600–800
Vdc
NOTE! The braking powers indicated in Table 103 can only be achieved with minimum resistance.
Table 102. Voltage levels
Voltage
Default +18% DC-link voltage level for braking
Vac 380 400 420 440 460 480 500
Vdc 513 540 567 594 621 648 675
U
br
+18%
605 637 669 701 733 765 797
Table 103. Maximum braking power
Chas-sis NXB unit
Thermal
current [Ith]
Max braking power at DC-link voltages [kW]
605 637 669 701 733 765 797
Ch3 NXB 0031_5 31 37.5 39.5 41.5 43.5 45.4 47.4 49.4
Ch3 NXB 0061_5 61 73.9 77.7 81.6 85.5 89.4 93.3 97.2
Ch4 NXB 0087_5 87 105.3 110.9 116.4 122.0 127.5 133.0 138.6
Ch4 NXB 0105_5 105 127.1 133.8 140.5 147.2 153.9 160.6 167.3
Ch4 NXB 0140_5 140 169.5 178.4 187.3 196.3 205.2 214.1 223.0
Ch5 NXB 0168_5 168 203.4 214.1 224.8 235.5 246.2 256.9 267.6
Ch5 NXB 0205_5 205 248.2 261.3 274.3 287.4 300.4 313.5 326.6
Ch5 NXB 0261_5 261 316.0 332.6 349.2 365.9 382.5 399.1 415.8
Ch61 NXB 0300_5 300 363.2 382.3 401.4 420.6 439.7 458.8 477.9
Ch61 NXB 0385_5 385 466.1 490.6 515.2 539.7 564.2 588.8 613.3
Ch62 NXB 0460_5 460 556.9 586.2 615.5 644.8 674.2 703.5 732.8
Ch62 NXB 0520_5 520 629.6 662.7 695.8 729.0 762.1 795.2 828.4
Ch62 NXB 0590_5 590 714.3 751.9 789.5 827.1 864.7 902.3 939.9
Ch62 NXB 0650_5 650 786.9 828.4 869.8 911.2 952.6 994.0 1035.5
Ch62 NXB 0730_5 730 883.8 930.3 976.8 1023.3 1069.9 1116.4 1162.9
Table 104. Minimum resistance
Chassis NXB unit
Thermal
current [Ith]
Minimum resistance at DC-link voltages [ohm]
605 637 669 701 733 765 797
Ch3 NXB 0031_5 31 19.5 20.6 21.6 22.6 23.6 24.7 25.7
Ch3 NXB 0061_5 61 9.9 10.4 11.0 11.5 12.0 12.5 13.1
Ch4 NXB 0087_5 87 7.0 7.3 7.7 8.1 8.4 8.8 9.2
Ch4 NXB 0105_5 105 5.8 6.1 6.4 6.7 7.0 7.3 7.6
Ch4 NXB 0140_5 140 4.3 4.6 4.8 5.0 5.2 5.5 5.7
Ch5 NXB 0168_5 168 3.6 3.8 4.0 4.2 4.4 4.6 4.7
Ch5 NXB 0205_5 205 3.0 3.1 3.3 3.4 3.6 3.7 3.9
