Vacon NX User Manual

10
vacon • 160 Active front end (NXA)
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
10.5 Power ratings
*) C = power loss into coolant, A = power loss into air, T = total power loss.
The enclosure class for all VACON
®
NX Liquid-Cooled AC drives is IP00.
I
th
= Thermal maximum continuous RMS current. Dimensioning can be done according to this
current if the process does not require any overloadability or the process does not include any load
variation.
I
L
= Low overloadability current. Allows +10% load variation. 10% exceeding can be continuous.
I
H
= High overloadability current. Allows +50% load variation. 50% exceeding can be continuous.
All values with cosϕ = 0.99 and efficiency = 97.5%.
*) c = power loss into coolant; a = power loss into air; T = total power loss.
All power losses obtained using max. supply voltage, I
th
and switching frequency of 3.6 kHz. All
power losses are worst case losses.
Table 62. Power ratings of VACON
®
NX Liquid-Cooled AFE unit, supply voltage 400-500 VAC
VACON
®
NX Liquid-Cooled Front End; DC Bus voltage 465–800 VDC
Active
front-
end type
AC Current DC power
Power loss
c/a/T*)
[kW]
Chassis
Thermal
I
th
[A]
Rated
I
L
[A]
Rated
I
H
[A]
400 VAC
mains
I
th
[kW]
500 VAC
mains
I
th
[kW]
400 VAC
mains
I
L
[kW]
500 VAC
mains
I
L
[kW]
0168_5 168 153 112 113 142 103 129 2.5/0.3/2.8 CH5
0205_5 205 186 137 138 173 125 157 3.0/0.4/3.4 CH5
0261_5 261 237 174 176 220 160 200 4.0/0.4/4.4 CH5
0300_5 300 273 200 202 253 184 230 4.5/0.4/4.9 CH61
0385_5 385 350 257 259 324 236 295 5.5/0.5/6.0 CH61
0460_5 460 418 307 310 388 282 352 5.5/0.5/6.0 CH62
0520_5 520 473 347 350 438 319 398 6.5/0.5/7.0 CH62
0590_5 590 536 393 398 497 361 452 7.5/0.6/8.1 CH62
0650_5 650 591 433 438 548 398 498 8.5/0.6/9.1 CH62
0730_5 730 664 487 492 615 448 559 10.0/0.7/10.7 CH62
0820_5 820 745 547 553 691 502 628 10.0/0.7/10.7 CH63
0920_5 920 836 613 620 775 563 704 12.4/0.8/12.4 CH63
1030_5 1030 936 687 694 868 631 789 13.5/0.9/14.4 CH63
1150_5 1150 1045 767 775 969 704 880 16.0/1.0/17.0 CH63
1370_5 1370 1245 913 923 1154 839 1049 15.5/1.0/16.5 CH64
1640_5 1640 1491 1093 1105 1382 1005 1256 19.5/1.2/20.7 CH64
2060_5 2060 1873 1373 1388 1736 1262 1578 26.5/1.5/28.0 CH64
2300_5 2300 2091 1533 1550 1938 1409 1762 29.6/1.7/31.3 CH64

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
