Vacon NX User Manual

Active front end (NXA) vacon • 161
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
10
*) C = power loss into coolant, A = power loss into air, T = total power loss.
The enclosure class for all VACON
®
NX Liquid-Cooled AC drives is IP00.
***) Mains voltage 640-1200 VDC for NX_8 inverter units.
I
th
= Thermal maximum continuous RMS current. Dimensioning can be done according to this
current if the process does not require any overloadability or the process does not include any load
variation.
I
L
= Low overloadability current. Allows +10% load variation. 10% exceeding can be continuous.
I
H
= High overloadability current. Allows +50% load variation. 50% exceeding can be continuous.
All values with cosϕ = 0.99 and efficiency = 97.5%.
*) c = power loss into coolant; a = power loss into air; T = total power loss.
All power losses obtained using max. supply voltage, I
th
and switching frequency of 3.6 kHz. All
power losses are worst case losses.
Table 63. Power ratings of VACON
®
NX Liquid-Cooled AFE unit, supply voltage 525-690 VAC
VACON
®
NX Liquid-Cooled Front End; DC Bus voltage 640–1100 VDC ***)
Active
front-
end type
AC Current DC power
Power loss
c/a/T*)
[kW]
Chassis
Thermal
I
th
[A]
Rated
I
L
[A]
Rated
I
H
[A]
525 VAC
mains
I
th
[kW]
690 VAC
mains
I
th
[kW]
525 VAC
mains
I
L
[kW]
690 VAC
mains
I
L
[kW]
0170_6 170 155 113 150 198 137 180 3.6/0.2/3.8 CH61
0208_6 208 189 139 184 242 167 220 4.3/0.3/4.6 CH61
0261_6 261 237 174 231 303 210 276 5.4/0.3/5.7 CH61
0325_6 325 295 217 287 378 261 343 6.5/0.3/6.8 CH61
0385_6 385 350 257 341 448 310 407 7.5/0.4/7.9 CH62
0416_6 416 378 277 368 484 334 439 8.0/0.4/8.4 CH62
0460_6 460 418 307 407 535 370 486 8.7/0.4/9.1 CH62
0502_6 502 456 335 444 584 403 530 9.8/0.5/10.3 CH62
0590_6 590 536 393 522 686 474 623 10.9/0.6/11.5 CH63
0650_6 650 591 433 575 756 523 687 12.4/0.7/13.1 CH63
0750_6 750 682 500 663 872 603 793 14.4/0.8/15.2 CH63
0820_6 820 745 547 725 953 659 866 15.4/0.8/16.2 CH64
0920_6 920 836 613 814 1070 740 972 17.2/0.9/18.1 CH64
1030_6 1030 936 687 911 1197 828 1088 19.0/1.0/20.0 CH64
1180_6 1180 1073 787 1044 1372 949 1247 21.0/1.1/22.1 CH64
1300_6 1300 1182 867 1150 1511 1046 1374 24.0/1.3/25.3 CH64
1500_6 1500 1364 1000 1327 1744 1207 1586 28.0/1.5/29.5 CH64
1700_6 1700 1545 1133 1504 1976 1367 1796 32.1/1.7/33.8 CH64

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
